Riverdi RVT43ALBFWR00 TFT LCD Colour Display / Touch Screen, 4.3in, 1280 x 768pixels
- RS Stock No.:
- 193-1156
- Mfr. Part No.:
- RVT43ALBFWR00
- Brand:
- Riverdi
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 193-1156
- Mfr. Part No.:
- RVT43ALBFWR00
- Brand:
- Riverdi
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Riverdi | |
| Diagonal Display Size | 4.3in | |
| Interface Type | SPI | |
| Resolution | 1280 x 768pixels | |
| Touch Screen | Yes | |
| Viewing Area Dimensions | 54 x 95mm | |
| Supply Voltage | 4 V | |
| Touch Screen Type | Resistive | |
| Backlight Type | LED | |
| AC or DC Input Voltage | dc | |
| Dimensions | 106.3 x 8.38 x 68mm | |
| Display Matrix Technology | TFT | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | +70°C | |
| Brightness | 440cd/m² | |
| Viewing Area Height | 95.04mm | |
| Width | 106.3mm | |
| Depth | 8.38mm | |
| Height | 68mm | |
| Current Rating | 25mA | |
| Viewing Area Width | 53.86mm | |
| Voltage Rating | 3.3V | |
| Display Type | TFT | |
| Operating Temperature Range | -20 → +70°C | |
Select all | ||
|---|---|---|
Brand Riverdi | ||
Diagonal Display Size 4.3in | ||
Interface Type SPI | ||
Resolution 1280 x 768pixels | ||
Touch Screen Yes | ||
Viewing Area Dimensions 54 x 95mm | ||
Supply Voltage 4 V | ||
Touch Screen Type Resistive | ||
Backlight Type LED | ||
AC or DC Input Voltage dc | ||
Dimensions 106.3 x 8.38 x 68mm | ||
Display Matrix Technology TFT | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature +70°C | ||
Brightness 440cd/m² | ||
Viewing Area Height 95.04mm | ||
Width 106.3mm | ||
Depth 8.38mm | ||
Height 68mm | ||
Current Rating 25mA | ||
Viewing Area Width 53.86mm | ||
Voltage Rating 3.3V | ||
Display Type TFT | ||
Operating Temperature Range -20 → +70°C | ||
- COO (Country of Origin):
- PL
The Riverdi RiTFT-35 series Intelligent Display solutions has a TFT, Transmissive, Normally white type of LCD. It has 3.3 V input voltage, RGB Vertical Stripe Pixel Arrangement.
Driver IC BT81x
Interface Type SPI/QSPI
Interface Type SPI/QSPI
