Grayhill 3 Key ABS Polycarbonate Keypad

  • RS Stock No. 877-8681
  • Mfr. Part No. 87EC3-201
  • Brand Grayhill
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

Grayhill 87 Series Modular Keypads

The 87 series modular keyboards have a low profile and plug into any printed circuit board from a 1/32nd to 1/8th thickness. Users can build a custom keyboard with identical button spacing’s no matter how they are stacked, always maintaining a 0.5 inch button centre. Each button has a life expectancy of 3,000,000 operations helping to reduce maintenance costs and increase reliability. These modules are unsealed and the snap-dome contacts provide positive feedback helping the user to be fully aware when a button has been pushed or not.

Features:
1, 2, 3, 4, 5 and 6 button individual key switches
12 and 16 button keypads
Maintain 0.5 inch button centres
Up to 3,000,000 operations per button
Low profile design

Specifications
Attribute Value
Keypad Layout 1 x 3
Number of Keys 3
Case Material ABS Polycarbonate
Case Colour Black
Mechanical Life Per Key 3000000Operations
Contact Material Phosphor Bronze
Actuator Colour White
Actuator Material ABS Plastic
Depth Behind Panel 8.9mm
Minimum Operating Temperature -40°C
Operating Temperature Range -40 → +80°C
Maximum Operating Temperature +80°C
Voltage Rating 24V dc
Available to back order for despatch 05/05/2020
Price Each
£ 5.97
(exc. VAT)
£ 7.16
(inc. VAT)
Units
Per unit
1 +
£5.97
