Phoenix Contact UM 45-D Series 9-Contact Female Interface Module, D-sub Connector, DIN Rail Mount, 2.5A
- RS Stock No.:
- 292-9521
- Distrelec Article No.:
- 148-01-498
- Mfr. Part No.:
- 2962722
- Brand:
- Phoenix Contact
Subtotal (1 unit)*
£40.48
(exc. VAT)
£48.58
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 19 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £40.48 |
*price indicative
- RS Stock No.:
- 292-9521
- Distrelec Article No.:
- 148-01-498
- Mfr. Part No.:
- 2962722
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Gender | Female | |
Wire Size | 26 → 16 AWG | |
Number of Contacts | 9 | |
Connector Type | D-sub | |
Mounting Type | DIN Rail Mount | |
Test Proof Voltage | 1.2kV | |
Voltage Rating | 125 V ac/dc | |
Current Rating | 2.5A | |
Cable CSA | 0.14 → 1.5mm² | |
Dimensions | 53 x 43.12 x 45mm | |
Depth | 45mm | |
Length | 53mm | |
Minimum Operating Temperature | -20°C | |
Series | UM 45-D | |
Maximum Operating Temperature | +50°C | |
Width | 43.12mm | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Gender Female | ||
Wire Size 26 → 16 AWG | ||
Number of Contacts 9 | ||
Connector Type D-sub | ||
Mounting Type DIN Rail Mount | ||
Test Proof Voltage 1.2kV | ||
Voltage Rating 125 V ac/dc | ||
Current Rating 2.5A | ||
Cable CSA 0.14 → 1.5mm² | ||
Dimensions 53 x 43.12 x 45mm | ||
Depth 45mm | ||
Length 53mm | ||
Minimum Operating Temperature -20°C | ||
Series UM 45-D | ||
Maximum Operating Temperature +50°C | ||
Width 43.12mm | ||
- COO (Country of Origin):
- DE
Phoenix Contact Interface Module, ≤22.5A Total Current Rating, 2.74mm Pitch - UM 45-D 9SUB/B - 2962722
Fly through wiring your automated signalling devices with this interface module from Phoenix Contact. It links sensor equipment straight to a control device to directly transfer data and support system reliability. With its standard 9-pin D-sub port, the unit plugs into a controller without any hassle and as it simply clips onto a DIN rail, fitting it in your cabinet is done without tools.
Don't worry about tightly packed systems, as the module measures just 53 (W) x 45 (H) x 43.12mm (D), so squeezes into tight spots. Thanks to its PVC insulation, you're not at risk of making contact with dangerous electrical loads during wiring. Compatibility with wires sized between 0.14 and 1.5mm² makes this a versatile connection option. As the unit carries at least 2.5A per branch, it keeps up with intense signalling tasks.
Don't worry about tightly packed systems, as the module measures just 53 (W) x 45 (H) x 43.12mm (D), so squeezes into tight spots. Thanks to its PVC insulation, you're not at risk of making contact with dangerous electrical loads during wiring. Compatibility with wires sized between 0.14 and 1.5mm² makes this a versatile connection option. As the unit carries at least 2.5A per branch, it keeps up with intense signalling tasks.
Features & Benefits
• Service life of at least 500 mating cycles for long-lasting connectivity
• Works in temperatures between -20°C and +50°C, so performs reliably in demanding environments
• Meets EN IEC 60664-1 standards for creepage and air clearance to prevent damage from arcing
• Works in temperatures between -20°C and +50°C, so performs reliably in demanding environments
• Meets EN IEC 60664-1 standards for creepage and air clearance to prevent damage from arcing
