AD8293G160BRJZ-R2 Analog Devices, Instrumentation Amplifier, 20μV Offset 500Hz, R-RO, 1.8 5.5 V, 8-Pin SOT-23

View all Instrumentation Amplifiers
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Packaging Options:
RS Stock No.:
820-9157
Mfr. Part No.:
AD8293G160BRJZ-R2
Brand:
Analog Devices
Find similar products by selecting one or more attributes.
Select all

Brand

Analog Devices

Power Supply Type

Single

Package Type

SOT-23

Mounting Type

Surface Mount

Typical Single Supply Voltage

1.8 5.5 V

Pin Count

8

Rail to Rail

Rail to Rail Output

Maximum Input Offset Voltage

20µV

Minimum Operating Temperature

-40 °C

Maximum Operating Temperature

+85 °C

Maximum Input Resistance

10GΩ

Minimum CMRR

110dB

Typical Gain Bandwidth Product

500Hz

Maximum Supply Current

2 nA

Dimensions

2.9 x 1.6 x 1.3mm

Length

2.9mm

Height

1.3mm

Width

1.6mm

Instrumentation Amplifiers, Analog Devices


The Instrumentation Amplifier ICs amplify the difference between two input signal voltages, while rejecting any signals that are common to both inputs. The DC precision and gain accuracy is maintained within a noisy environment, and also where large common-mode signals (AC power line frequency) are present.


Instrumentation Amplifiers, Analog Devices


A range of Instrumentation Amplifiers from Analog Devices. This range of products also includes numerous evaluation and development boards.
