Hirose Circular Connector, 10 Contacts, Cable Mount, Miniature Connector, RM Series
- RS Stock No.:
- 636-1957
- Mfr. Part No.:
- RM15TPD-10P(76)
- Brand:
- Hirose
Bulk discount available
Subtotal (1 unit)*
£17.02
(exc. VAT)
£20.42
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 106 unit(s) shipping from 06 October 2025
- Plus 1 unit(s) shipping from 06 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 14 | £17.02 |
15 - 49 | £15.35 |
50 - 99 | £13.78 |
100 + | £12.40 |
*price indicative
- RS Stock No.:
- 636-1957
- Mfr. Part No.:
- RM15TPD-10P(76)
- Brand:
- Hirose
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Hirose | |
Number of Contacts | 10 | |
Mounting Type | Cable Mount | |
Connector Size | Miniature | |
Body Orientation | Straight | |
Series | RM | |
Voltage Rating | 350.0 V | |
Housing Material | Aluminium Alloy, Brass, Zinc Alloy | |
Contact Material | Brass, Copper | |
Select all | ||
---|---|---|
Brand Hirose | ||
Number of Contacts 10 | ||
Mounting Type Cable Mount | ||
Connector Size Miniature | ||
Body Orientation Straight | ||
Series RM | ||
Voltage Rating 350.0 V | ||
Housing Material Aluminium Alloy, Brass, Zinc Alloy | ||
Contact Material Brass, Copper | ||
- COO (Country of Origin):
- JP
Hirose Circular Connector
The Hirose RM series 10-contacts male circular connector has a plug in-line type connection. This cable mount connector has a voltage rating of 350VAC/490VDC and a current rating of up to 5A per contact. This connector features a threaded coupling locking mechanism for an easy and secure connection with five keys in the fitting section to assure smooth coupling. It is a rugged miniaturized circular connector is made from nickel-plated brass and zinc alloy with a synthetic resin insulator.
Note:
For strain relief, see Hirose JR range
Hirose RM range
10-way standard (15mm mating face dia.) connectors for video equipment. Consisting of cable or chassis mounting plugs and sockets with metal shells and solder type terminations.
Note:
For strain relief, see Hirose JR range
Hirose RM range
10-way standard (15mm mating face dia.) connectors for video equipment. Consisting of cable or chassis mounting plugs and sockets with metal shells and solder type terminations.
Features and Benefits
Straight body orientation
Solder termination
2000 mating cycles
Easy mating and unmating
Excellent mechanical and electrical performance
Minimum wire size is 20AWG
Operation temperature ranging between -25°C and 85°C
Shell size is 15mm
Unshielded
Solder termination
2000 mating cycles
Easy mating and unmating
Excellent mechanical and electrical performance
Minimum wire size is 20AWG
Operation temperature ranging between -25°C and 85°C
Shell size is 15mm
Unshielded
Applications
Audio and video applications
Radio equipment
Radio equipment
Certifications
UL approved
