Jaeger Circular Connector, 3 Contacts, Panel Mount, Female

RS Stock No.:: 285-4938
Mfr. Part No.:: 5366 030 06
Brand:: Jaeger

Jaeger Circular Connector, 3 Contacts, Panel Mount, Female

7 In stock - FREE next working day delivery available

180 available from Europe for delivery within 1 working day(s).

Price Each

£16.04

(exc. VAT)

£19.25

(inc. VAT)

Units	Per unit
1 - 9	£16.04
10 - 24	£14.44
25 +	£12.85

RS Stock No.:: 285-4938
Mfr. Part No.:: 5366 030 06
Brand:: Jaeger

Technical Reference

Rapid Series Quick Disconnect Receptacles Plugs and Cable Connecting Plugs Data Sheet

Legislation and Compliance

COO (Country of Origin):: FR

Product Details

Standard Chassis Plug and Socket

Standard series chassis sockets are also compatible with the ’Rapid’ series cable plug

Note

Cable plug mates with chassis socket, cable socket mates with chassis plug only, in-line not possible.

Jaeger Standard & Rapid Range

Specifications

Attribute	Value
Number of Contacts	3
Mounting Type	Panel Mount
Contact Gender	Female
Termination Method	Solder
Body Orientation	Straight
Shell Size	1
Minimum Operating Temperature	-50°C
Maximum Operating Temperature	+100°C
