Molex Circular Connector, 3 Contacts, Cable Mount, M8 Connector, Socket, Female, IP67, Nano-Change Series
- RS Stock No.:
- 180-5754
- Mfr. Part No.:
- 1200910003
- Brand:
- Molex
Subtotal (1 unit)*
£10.19
(exc. VAT)
£12.23
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 34 unit(s), ready to ship
Units | Per unit |
---|---|
1 + | £10.19 |
*price indicative
- RS Stock No.:
- 180-5754
- Mfr. Part No.:
- 1200910003
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Molex | |
Number of Contacts | 3 | |
Mounting Type | Cable Mount | |
Connector Size | M8 | |
Plug/Socket | Socket | |
Contact Gender | Female | |
Termination Method | Screw | |
IP Rating | IP67 | |
Current Rating | 4.0A | |
Series | Nano-Change | |
Body Orientation | Right Angle | |
Voltage Rating | 60.0 V , 75.0 V | |
Mating Type | Threaded | |
Housing Material | Nylon | |
Pole Format | 3P | |
Contact Plating | Nickel | |
Minimum Operating Temperature | 0.0°C | |
Contact Material | Brass | |
Maximum Operating Temperature | +80°C | |
Series Number | 120091 | |
Select all | ||
---|---|---|
Brand Molex | ||
Number of Contacts 3 | ||
Mounting Type Cable Mount | ||
Connector Size M8 | ||
Plug/Socket Socket | ||
Contact Gender Female | ||
Termination Method Screw | ||
IP Rating IP67 | ||
Current Rating 4.0A | ||
Series Nano-Change | ||
Body Orientation Right Angle | ||
Voltage Rating 60.0 V , 75.0 V | ||
Mating Type Threaded | ||
Housing Material Nylon | ||
Pole Format 3P | ||
Contact Plating Nickel | ||
Minimum Operating Temperature 0.0°C | ||
Contact Material Brass | ||
Maximum Operating Temperature +80°C | ||
Series Number 120091 | ||
- COO (Country of Origin):
- DE
Molex Nano-Change Series Circular Connector, 3 Contact Points, IP67 - 1200910003
This circular connector is specifically designed for efficient and reliable connection in various demanding applications. The M8 circular connector features a female socket for easy integration into systems requiring a secure connection. This product boasts a right-angle body orientation, ideal for tight spaces, and an IP67 rating, ensuring protection against dust and water ingress. Its nylon housing and gold-plated copper alloy contacts provide durability and optimal conductivity.
Features & Benefits
• Designed for cable mounting, ensuring secure installation
• Female socket design allows easy pairing with male connectors
• Rated up to 4A, suitable for various power usage
• IP67 rated connectors protect against dust and moisture
• Features screw termination for reliable electrical connections
• Operates within a temperature range of 0°C to +80°C
• Female socket design allows easy pairing with male connectors
• Rated up to 4A, suitable for various power usage
• IP67 rated connectors protect against dust and moisture
• Features screw termination for reliable electrical connections
• Operates within a temperature range of 0°C to +80°C
Applications
• Used in automation systems for seamless component connections
• Ideal for electrical and mechanical requiring rugged connectors
• Suitable for outdoor environments requiring weather-resistant solutions
• Effective in industrial machinery where space restrictions are critical
• Ideal for electrical and mechanical requiring rugged connectors
• Suitable for outdoor environments requiring weather-resistant solutions
• Effective in industrial machinery where space restrictions are critical
What are the benefits of the screw termination method in this connector?
The screw termination method provides a robust and secure connection that is ideal for environments where vibrations or movement could lead to disconnections. It ensures a permanent attachment that can handle a range of wire sizes, making it suitable for diverse applications.
How does the IP67 rating enhance the reliability of this connector?
An IP67 rating signifies that the connector is completely dust-tight and can withstand immersion in water up to 1 metre for a limited time. This makes it reliable for use in harsh environments, ensuring consistent performance in both indoor and outdoor settings.
What types of installations can benefit from the right-angle orientation of this connector?
The right-angle orientation is particularly advantageous in installations with limited space, allowing for easier routing of cables and reducing strain on connections. This design feature helps to maintain the integrity of the installation in compact or cluttered areas.
