Bulgin Circular Connector, 4 Contacts, Cable Mount, M8 Connector, Socket, Female, IP67, Buccaneer M8 Series
- RS Stock No.:
- 144-6717
- Distrelec Article No.:
- 300-88-700
- Mfr. Part No.:
- PXPPAM08FBF04AST
- Brand:
- Bulgin
Subtotal (1 unit)*
£21.56
(exc. VAT)
£25.87
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 36 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £21.56 |
*price indicative
- RS Stock No.:
- 144-6717
- Distrelec Article No.:
- 300-88-700
- Mfr. Part No.:
- PXPPAM08FBF04AST
- Brand:
- Bulgin
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Number of Contacts | 4 | |
| Mounting Type | Cable Mount | |
| Connector Size | M8 | |
| Plug/Socket | Socket | |
| Contact Gender | Female | |
| Termination Method | Screw | |
| IP Rating | IP67 | |
| Current Rating | 3.0A | |
| Body Orientation | Straight | |
| Series | Buccaneer M8 | |
| Voltage Rating | 30.0 V | |
| Coding | A | |
| Shell Size | 12 | |
| Mating Type | Threaded | |
| Housing Material | Polymer | |
| Pole Format | 4 | |
| Contact Plating | Gold | |
| Strain Relief | No | |
| Contact Material | Bronze | |
| Maximum Operating Temperature | +80°C | |
| Minimum Operating Temperature | -25°C | |
Select all | ||
|---|---|---|
Brand Bulgin | ||
Number of Contacts 4 | ||
Mounting Type Cable Mount | ||
Connector Size M8 | ||
Plug/Socket Socket | ||
Contact Gender Female | ||
Termination Method Screw | ||
IP Rating IP67 | ||
Current Rating 3.0A | ||
Body Orientation Straight | ||
Series Buccaneer M8 | ||
Voltage Rating 30.0 V | ||
Coding A | ||
Shell Size 12 | ||
Mating Type Threaded | ||
Housing Material Polymer | ||
Pole Format 4 | ||
Contact Plating Gold | ||
Strain Relief No | ||
Contact Material Bronze | ||
Maximum Operating Temperature +80°C | ||
Minimum Operating Temperature -25°C | ||
- COO (Country of Origin):
- CN
Bulgin's M8 circular connectors and over molded cables are designed to fulfil the ever growing demand for sensor , actuator and data connections in process control, industrial machinery and factory automation applications. These compact sensor and automation connectors with screw lock coupling are mechanically and chemically robust, easy to install, minimise downtime and help to increase production efficiency. Rated to the IP67 standard, Bulgin's M8 Series ensure safe, secure and reliable protection from liquids, dust, moisture and dirt whilst also providing great resistance against vibrations to ensure that connections are not disrupted.
Straight & right angled configurations
3, 4 or 5 contacts
Metal & plastic shell options
A & B coded
Environmental protection class IP67
Field installable connectors, panel mounts & overmolded cable options
PVC or PUR jacketed cable variants with many lengths from 1m – 15m
3, 4 or 5 contacts
Metal & plastic shell options
A & B coded
Environmental protection class IP67
Field installable connectors, panel mounts & overmolded cable options
PVC or PUR jacketed cable variants with many lengths from 1m – 15m
M8 Flex Body Female
Available in 3 and 4 poles
Screw termination
Plastic Flex Body
Mates with Flex Inline Body and panel mount connectors
Screw termination
Plastic Flex Body
Mates with Flex Inline Body and panel mount connectors
