RS PRO Circular Connector, 9 Contacts, Flange Mount, Plug, Male, IP68

RS Stock No.:: 144-4209
Brand:: RS PRO

RS PRO Circular Connector, 9 Contacts, Flange Mount, Plug, Male, IP68

12 In stock - FREE next working day delivery available

Added

Price Each

£14.92

(exc. VAT)

£17.90

(inc. VAT)

Units	Per unit
1 - 9	£14.92
10 - 49	£14.18
50 - 99	£13.40
100 +	£12.66

RS Stock No.:: 144-4209
Brand:: RS PRO

Technical Reference

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

2 Hole Flange Mount Plug and Socket 5A/15A/30A Circular Connectors (Threaded) IP68

From RS Pro, these threaded plug and sockets are serious contenders for your application. This particular model has a bigger and stronger shell complimented by its 2 hole flange-mounted connection. That coupled with the IP68 rating, makes sure that this industrial connector excels in harsh environments. When choosing a male or female connector, this version should really be one you consider.

Features and Benefits

5 way, 7 way, 9 way and 12 way available

Solder contact termination

High-quality Nylon66 shell

Panel hole cutout diameter: 21 mm

Specifications

Attribute	Value
Number of Contacts	9
Mounting Type	Flange Mount
Connector Size	Standard
Plug/Socket	Plug
Contact Gender	Male
Termination Method	Solder
IP Rating	IP68
Current Rating	5.0A
Body Orientation	Straight
Voltage Rating	500 V
Mating Type	Threaded
Housing Material	Nylon
Pole Format	9P
Contact Plating	Gold
Contact Material	Brass
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+85°C
