RS PRO Circular Connector, 2 Contacts, Bulkhead Mount, Socket, Female, IP68
- RS Stock No.:
- 144-4165
- Brand:
- RS PRO
17 In stock - FREE next working day delivery available
2 available from Europe for delivery within 1 working day(s).
Added
Price Each
£11.65
(exc. VAT)
£13.98
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £11.65 |
| 10 - 49 | £11.07 |
| 50 - 99 | £10.49 |
| 100 + | £9.91 |
- RS Stock No.:
- 144-4165
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
RS PRO Bulkhead Mounting Circular Connector, 2 Contacts
Use this RS PRO bulkhead mounting circular connector to establish either inline or cable-to-panel connections. This plug and socket combination simultaneously transmits data, signals and power in industrial components.
The nylon housing makes the product robust and resistant to extreme temperature variances and other environmental factors so it will protect your cables against damage in these harsh conditions. You can be sure of continued and reliant power and signal transmissions as the gold-plated brass contact material is highly conductive and withstands corrosion that can interrupt these transfers.
This connector's Ingress Protection (IP) rating of IP68 rating ensures it won't be damaged when submerged in water and is sealed against particles like dust and other corrosives. Use this connector for medical equipment and communications systems.
The nylon housing makes the product robust and resistant to extreme temperature variances and other environmental factors so it will protect your cables against damage in these harsh conditions. You can be sure of continued and reliant power and signal transmissions as the gold-plated brass contact material is highly conductive and withstands corrosion that can interrupt these transfers.
This connector's Ingress Protection (IP) rating of IP68 rating ensures it won't be damaged when submerged in water and is sealed against particles like dust and other corrosives. Use this connector for medical equipment and communications systems.
Features and Benefits
• Straight body orientation
• Standard connector size
• Female contact gender
• Brass contact material
• Gold contact plating
• Current rating of 10 A
• Nylon housing material
• IP68 rating
• Threaded mating type
• Maximum operating temperature of +85°C
• Minimum operating temperature of -25°C
• Bulkhead mounting type
• Two contacts
• Socket
• Pole format of 2P
• Solder termination method
• Voltage rating of 500 V
• Standard connector size
• Female contact gender
• Brass contact material
• Gold contact plating
• Current rating of 10 A
• Nylon housing material
• IP68 rating
• Threaded mating type
• Maximum operating temperature of +85°C
• Minimum operating temperature of -25°C
• Bulkhead mounting type
• Two contacts
• Socket
• Pole format of 2P
• Solder termination method
• Voltage rating of 500 V
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 2 |
| Mounting Type | Bulkhead Mount |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Contact Gender | Female |
| Termination Method | Solder |
| IP Rating | IP68 |
| Current Rating | 10.0A |
| Body Orientation | Straight |
| Voltage Rating | 500 V |
| Mating Type | Threaded |
| Housing Material | Nylon |
| Pole Format | 2P |
| Contact Plating | Gold |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Contact Material | Brass |
