RS PRO Circular Connector, 5 Contacts, Panel Mount, Socket, Female, IP68
- RS Stock No.:
- 124-6679
- Brand:
- RS PRO
3 In stock - FREE next working day delivery available
Added
Price Each
£22.09
(exc. VAT)
£26.51
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £22.09 |
| 10 - 49 | £20.99 |
| 50 - 99 | £19.89 |
| 100 + | £18.74 |
- RS Stock No.:
- 124-6679
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
2 Hole Flange Mount Socket 10A Circular Connectors (Threaded) IP68
From RS Pro, these threaded sockets are serious contenders for your application. This particular model has a bigger and stronger shell complimented by its 2 hole flange-mounted connection. That coupled with the IP68 rating, makes sure that this industrial connector excels in harsh environments. When choosing a female connector, this version should really be one you consider.
Features & Benefits
• 2 way, 3 way and 5 way available
• Cable outer diameter acceptance: 4.5 mm - 7 mm
• Screw contact termination
• High-quality Nylon66 shell
• Panel hole cutout diameter: 21 mm
• Cable outer diameter acceptance: 4.5 mm - 7 mm
• Screw contact termination
• High-quality Nylon66 shell
• Panel hole cutout diameter: 21 mm
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 5 |
| Mounting Type | Panel Mount |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Contact Gender | Female |
| Termination Method | Screw |
| IP Rating | IP68 |
| Current Rating | 10A |
| Body Orientation | Straight |
| Voltage Rating | 500 V |
| Mating Type | Threaded |
| Housing Material | Polymer |
| Pole Format | 5P |
| Contact Plating | Gold |
| Contact Material | Brass |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -25°C |
