RS PRO Red 0.33mm² Hook Up Wire, 22 AWG, 17/0.16 mm, 100m, XLPE Insulation
- RS Stock No.:
- 872-5280
- Brand:
- RS PRO
Subtotal (1 reel of 100 metres)*
£21.83
(exc. VAT)
£26.20
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 187 unit(s) ready to ship
- Plus 18 unit(s) ready to ship from another location
- Plus 120 unit(s) shipping from 09 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £21.83 | £0.218 |
*price indicative
- RS Stock No.:
- 872-5280
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Cross Sectional Area | 0.33mm² | |
| Sheath Colour | Red | |
| American Wire Gauge | 22 AWG | |
| Core Strands | 17/0.16 mm | |
| Length | 100m | |
| Insulation Material | XLPE | |
| Outer Diameter | 1.58mm | |
| Voltage Rating | 300 V | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | 0°C | |
| Conductor Material | Tinned Copper | |
| Wire Style | UL3266 | |
| Standards Met | UL 1581, UL 758 | |
| Insulation Wall Thickness | 0.4mm | |
| Size of Strands | 0.16mm | |
| Number of Strands | 17 | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Cross Sectional Area 0.33mm² | ||
Sheath Colour Red | ||
American Wire Gauge 22 AWG | ||
Core Strands 17/0.16 mm | ||
Length 100m | ||
Insulation Material XLPE | ||
Outer Diameter 1.58mm | ||
Voltage Rating 300 V | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature 0°C | ||
Conductor Material Tinned Copper | ||
Wire Style UL3266 | ||
Standards Met UL 1581, UL 758 | ||
Insulation Wall Thickness 0.4mm | ||
Size of Strands 0.16mm | ||
Number of Strands 17 | ||
- COO (Country of Origin):
- CN
RS PRO Red, 0.33 mm² Hook Up Wire, 100 m
Use this RS PRO hook-up wire for the internal wiring of equipment. The wire's conductors are made from tinned copper, which offers excellent conductivity to ensure a reliable transmission of electrical signal. This material is also resistant to corrosion, meaning your wire will have a longer service life.
The wire is insulated with cross-linked polythene (XPLE), which offers excellent thermal insulation. This means that the cable can withstand temperatures of up to +125°C, so it's safe to use it in demanding industrial settings. As it has passed the VW-1 flammability test, it's also designated as a fire-resistant, general-use cable.
This product meets the Underwriters' Laboratories UL 1581 and UL 758 standards for safety and efficacy. It also complies with Restriction of Hazardous Substances (RoHS) standards, meaning it contains only trace levels of any harmful materials.
The wire is insulated with cross-linked polythene (XPLE), which offers excellent thermal insulation. This means that the cable can withstand temperatures of up to +125°C, so it's safe to use it in demanding industrial settings. As it has passed the VW-1 flammability test, it's also designated as a fire-resistant, general-use cable.
This product meets the Underwriters' Laboratories UL 1581 and UL 758 standards for safety and efficacy. It also complies with Restriction of Hazardous Substances (RoHS) standards, meaning it contains only trace levels of any harmful materials.
Features and Benefits
- Hookup wire type
- Wire size of 22 American Wire Gauge (AWG)
- Cross-sectional area of 0.33 mm²
- Insulation wall thickness of 0.4 mm
- Length of 100 m
- 17 core strands of 0.16 mm
- Outer diameter of 1.58 mm
- Red sheath colour
- Maximum operating temperature of +125°C
- Minimum operating temperature of 0°C
- Cross-linked polythene (XPLE) insulation material
- Tinned copper conductor material
- Voltage rating of 300 V
- UL3266 wire style
- Restriction of Hazardous Substances (RoHS) compliant
- Underwriters' Laboratories UL 1581 and UL 758 compliant
