Molex 93601 Heavy Duty Power Connector Hood, M25 Thread, Side Entry

View this category

Subtotal (1 unit)*

£11.17

(exc. VAT)

£13.40

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 134 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£11.17

*price indicative

RS Stock No.:
250-2027
Distrelec Article No.:
302-99-695
Mfr. Part No.:
936010914
Brand:
Molex
Find similar products by selecting one or more attributes.
Select all

Brand

Molex

Series

93601

Type

STD

Thread Size

M25

Size

6B

Body Orientation

Side Entry

IP Rating

IP66

Cable Entry Angle

Side

Voltage Rating

500 V

Contact Material

Aluminium Alloy

Series Number

93601

For Use With

S-DD, S-E, S-EHV Inserts, S-EP, S-ES, S-ESHV, S-HSB, S-K, S-M, SEE, Size 6B (44x27) S-D

Number of Levers

1

COO (Country of Origin):
CN

Molex 93601 Series Heavy Duty Power Connector Hood, M25 Thread size, 500V Voltage Rating - 936010914


This heavy duty power connector hood is designed to provide robust protection for industrial applications. It features a Standard Single Lever design made from die-cast aluminium, ensuring durability and reliability in challenging environments. With an IP66 rating, it effectively protects against dust and water ingress, making it an ideal choice for various industrial power connector solutions.

Features & Benefits


• High voltage rating of 500V supports complex systems
• Two stainless steel pegs enhance mechanical stability
• IP66 rating provides excellent dust and water resistance
• Compatible with size 6B connectors for flexible usage

Applications


• Used with size 6B inserts for secure connections
• Suitable for automation systems requiring durable electrical components
• Ideal for electronic and mechanical in harsh environments
• Utilised in heavy machinery needing reliable power connections

How does the design of this connector hood accommodate various cable orientations?


The side entry feature allows for straightforward cable routing, ensuring minimal stress on connections and optimal space management within enclosures.

What material properties of the hood enhance its longevity in industrial environments?


The die-cast aluminium construction exhibits excellent resistance to corrosion and wear, while the polyester powder coating adds an extra layer of protection against environmental factors.

How does the connector hood's IP66 rating benefit users in practice?


An IP66 rating ensures that the hood is fully protected against dust ingress and water jets, maintaining operational integrity in outdoor or wet conditions.

What types of inserts can be used with this hood?


It is specifically designed to be compatible with various size 6B inserts, including S-D, S-DD, S-E, and more, providing flexibility in its application.
