Moflash AB6 Series Wall Mount Siren, 115 V ac, 100dB at 1 m, IP44, AC, Single-Tone
- RS Stock No.:
- 851-3416
- Mfr. Part No.:
- AB6-115AC
- Brand:
- Moflash
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 851-3416
- Mfr. Part No.:
- AB6-115AC
- Brand:
- Moflash
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Moflash | |
Supply Voltage | 115 V ac | |
IP Rating | IP44 | |
Decibels at 1 Metre | 100dB | |
Current Type | AC | |
Number Of Tones | 1 | |
Housing Colour | Grey | |
Mounting Style | Wall Mount | |
Diameter | 167 mm | |
Application Type | Bell | |
Maximum Decibel | 100dB | |
Series | AB6 | |
Housing Material | Aluminium | |
Standards Met | CE Certified UKCA | |
Minimum Temperature | -20°C | |
Maximum Temperature | +45°C | |
Select all | ||
---|---|---|
Brand Moflash | ||
Supply Voltage 115 V ac | ||
IP Rating IP44 | ||
Decibels at 1 Metre 100dB | ||
Current Type AC | ||
Number Of Tones 1 | ||
Housing Colour Grey | ||
Mounting Style Wall Mount | ||
Diameter 167 mm | ||
Application Type Bell | ||
Maximum Decibel 100dB | ||
Series AB6 | ||
Housing Material Aluminium | ||
Standards Met CE Certified UKCA | ||
Minimum Temperature -20°C | ||
Maximum Temperature +45°C | ||
- COO (Country of Origin):
- TW
Moflash AB6 Solenoid Driven Bell
The AB6 bells from Moflash are suitable for light commercial/industrial use where intermittent audible signalling is required in a localised area. The distinctive sound of these traditional type bells is produced by means of a solenoid driven striker repeatedly striking the inside edge of the metal gong, resulting in a loud and clear ringing tone.
The bells can be mounted on any flat surface utilising either the four mounting holes that are incorporated into the body of the casting or the universal mounting plate and gasket (supplied as standard) that offers multiple fixing location options.
The bells can be mounted on any flat surface utilising either the four mounting holes that are incorporated into the body of the casting or the universal mounting plate and gasket (supplied as standard) that offers multiple fixing location options.
Economy signal
Distinctive sound
Die-cast aluminium body and steel gong
Universal mounting plate
Supplied with 150mm flying leads
Powder coated gong
IP44 rating
RoHS compliant
CE marked
Distinctive sound
Die-cast aluminium body and steel gong
Universal mounting plate
Supplied with 150mm flying leads
Powder coated gong
IP44 rating
RoHS compliant
CE marked
Moflash Grey Single-Tone Siren, 115V AC, 100dB - AB6 Solenoid Series - AB6-115AC
Use this grey single-tone siren from Moflash to create an audible alert in your workplace. When actuated, its solenoid-driven striker makes repeated contact with a metal gong to produce a clear, easily recognisable ringing tone. Its loud sound output of 100dB (decibels) at a distance of 1m makes it highly audible to those in the surrounding area. It comes with a universal mounting plate, so it's simple to install this device on any flat surface. Thanks to its die-cast aluminium construction, it's resistant to corrosion and impact for long-lasting use.
Features & Benefits
• IP44 (ingress protection) rating means it's protected against water splashes and objects larger than 1mm in size
• Powder-coated gong resists corrosion for a long service life
• Powder-coated gong resists corrosion for a long service life
Applications
• Mechanical and automation industries
• Process and packaging plants
• Process and packaging plants
What's the operating temperature range of this siren?
This siren has a wide operating temperature range between -20°C and +45°C, so it's a good choice for use in demanding environments.
Is this siren energy-efficient?
Yes, this siren has a low current consumption of just 60mA, making it an energy-efficient choice.
