Portescap Micro Linear Actuator, 76.2mm, 12V dc, 88N
- RS Stock No.:
- 510-1120
- Mfr. Part No.:
- 57DBM10B2U-L
- Brand:
- Portescap
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£141.03
(exc. VAT)
£169.24
(inc. VAT)
- RS Stock No.:
- 510-1120
- Mfr. Part No.:
- 57DBM10B2U-L
- Brand:
- Portescap
Specifications
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Portescap | |
| Actuator Type | Micro Linear Actuator | |
| Maximum Stroke Length | 76.2mm | |
| Maximum Load | 88N | |
| Input Voltage | 12V dc | |
| Series | 57DBM10B2U | |
Select all | ||
|---|---|---|
Brand Portescap | ||
Actuator Type Micro Linear Actuator | ||
Maximum Stroke Length 76.2mm | ||
Maximum Load 88N | ||
Input Voltage 12V dc | ||
Series 57DBM10B2U | ||
RoHS Status: Not Applicable
- COO (Country of Origin):
- MY
Miniature Linear Actuators
A non-captive linear actuator that provides a long stroke length and up to 128 oz of linear force in a 26 mm frame size. The 7.5 degree step angle and option of 0.0005" lead screw pitch options allows for greater positional resolution.
Features and Benefits
High continuous linear force output for size
Digitally controlled - easy to use with a micro processor
Cost effective - compact design, lower integration cost
Maintenance free - no brushes to replace
Unipolar and bipolar winding options
Captive and non-captive designs
Long life - ball bearing design
Product Application Information
Motors for medical pipettes
Damper actuation
Flap actuation
Printers and copiers
Switching systems
