Phoenix Contact 3047688 UT Series Feed Through Terminal Block Red, 0.14mm², 6 mm², 1-Level, Screw
- RS Stock No.:
- 858-0270
- Mfr. Part No.:
- 3047688
- Brand:
- Phoenix Contact
Subtotal (1 box of 50 units)*
£91.43
(exc. VAT)
£109.72
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 11 January 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £91.43 | £1.829 |
*price indicative
- RS Stock No.:
- 858-0270
- Mfr. Part No.:
- 3047688
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Colour | Red | |
| Product Type | Feed Through Terminal Block | |
| Number of Levels | 1 | |
| Number of Positions | 1 | |
| Voltage | 800V | |
| Series | UT | |
| Minimum Wire Size AWG | 26AWG | |
| Cable CSA | 0.14mm², 6mm² | |
| Maximum Wire Size AWG | 10AWG | |
| Terminal Block Current | 41A | |
| Termination Type | Screw | |
| Hazardous Area Certification | No | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Colour Red | ||
Product Type Feed Through Terminal Block | ||
Number of Levels 1 | ||
Number of Positions 1 | ||
Voltage 800V | ||
Series UT | ||
Minimum Wire Size AWG 26AWG | ||
Cable CSA 0.14mm², 6mm² | ||
Maximum Wire Size AWG 10AWG | ||
Terminal Block Current 41A | ||
Termination Type Screw | ||
Hazardous Area Certification No | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- DE
Feed-through terminal block, nom. voltage: 800 V, nominal current: 41 A, connection method: Screw connection, number of connections: 2, number of positions: 1, cross section: 0.14 mm² - 6 mm², AWG: 26 - 10, width: 6.2 mm, color: red, mounting type: NS 35/7,5, NS 35/15
