Siemens LOGO!POWER Switch Mode DIN Rail Panel Mount Power Supply, 85 → 264V ac ac, dc Input, 12V dc dc Output,
- RS Stock No.:
- 734-2705
- Mfr. Part No.:
- 6EP1321-1SH03
- Brand:
- Siemens
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 734-2705
- Mfr. Part No.:
- 6EP1321-1SH03
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Series | LOGO!POWER | |
| Type | Switch Mode | |
| Electrical Phase | 1 | |
| AC or DC Input Voltage | ac, dc | |
| Number of Outputs | 1 | |
| Input Voltage | 85 → 264V ac | |
| AC or DC Output Voltage | dc | |
| Output Voltage | 12V dc | |
| Output Current | 1.9A | |
| Dimensions | 55 x 54 x 90mm | |
| Width | 54mm | |
| Height | 90mm | |
| Depth | 52.6mm | |
| Maximum Temperature | +70°C | |
| Minimum Temperature | -20°C | |
| Output Voltage Adjustment Range | 10.5 → 16.1V | |
| Mounting Type | DIN Rail Mount | |
| Hazardous Area Certification | ATEX | |
| Ripple And Noise | 200mV Pk-Pk | |
| Load Regulation | 1.5% | |
Select all | ||
|---|---|---|
Brand Siemens | ||
Series LOGO!POWER | ||
Type Switch Mode | ||
Electrical Phase 1 | ||
AC or DC Input Voltage ac, dc | ||
Number of Outputs 1 | ||
Input Voltage 85 → 264V ac | ||
AC or DC Output Voltage dc | ||
Output Voltage 12V dc | ||
Output Current 1.9A | ||
Dimensions 55 x 54 x 90mm | ||
Width 54mm | ||
Height 90mm | ||
Depth 52.6mm | ||
Maximum Temperature +70°C | ||
Minimum Temperature -20°C | ||
Output Voltage Adjustment Range 10.5 → 16.1V | ||
Mounting Type DIN Rail Mount | ||
Hazardous Area Certification ATEX | ||
Ripple And Noise 200mV Pk-Pk | ||
Load Regulation 1.5% | ||
RoHS Status: Not Applicable
- COO (Country of Origin):
- AT
SITOP LOGO!Power
Our miniature power supply units in the same design as the logic modules offer great performance in the smallest space. Efficiency has been improved across the entire load range, and the low-power losses in no-load operation ensure efficient operation. The power supplies are suitable for universal use due to their wide-range input for single phase networks and operation with direct voltage. They also have a wide operating temperature range, comprehensive certifications and switch-on behaviour optimised for capacitive loads. These reliable power supplies with their flat, stepped profile can be used flexibly in numerous applications such as in distribution boards.
To increase the 24 V availability, the LOGO!Power supplies can be combined with DC UPS, redundancy and selectivity modules.
To increase the 24 V availability, the LOGO!Power supplies can be combined with DC UPS, redundancy and selectivity modules.
Features and Benefits
• Single phase, wide input range 85 V to 264 V ac or 110 V to 300 V dc
• Power reserve on starting up through 1.5 times the rated current for capacitive loads
• Wide temperature range: -20°C to 70°C
• Installation depth of 55 mm
• High efficiency across the entire load range
Approvals
cULus, cURus, NEC class 2, CE, CB, FM, ATEX, cCSAus Class I Div. 2, GL, ABS
Warning
This product is in obsolescence mode and is due for discontinuation by the manufacturer. We recommend that you review alternative highlighted by the manufacturer. Alternatively, refer to the cross reference list in the Technical Reference section which highlights the upgrade path for your current generation of products.
