Phoenix Contact STEP POWER Switched Mode DIN Rail Power Supply, 100 → 240 V, 110 → 250 V ac Input, 24V dc
- RS Stock No.:
- 239-5082
- Distrelec Article No.:
- 303-09-465
- Mfr. Part No.:
- 1088495
- Brand:
- Phoenix Contact
Subtotal (1 unit)*
£34.18
(exc. VAT)
£41.02
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 30 unit(s) ready to ship
- Plus 9 unit(s) ready to ship from another location
- Plus 30 unit(s) shipping from 29 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £34.18 |
*price indicative
- RS Stock No.:
- 239-5082
- Distrelec Article No.:
- 303-09-465
- Mfr. Part No.:
- 1088495
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Series | STEP POWER | |
Type | Switched Mode | |
Electrical Phase | 1 | |
AC or DC Input Voltage | ac | |
Input Voltage | 100 → 240 V, 110 → 250 V | |
AC or DC Output Voltage | dc | |
Output Voltage | 24V dc | |
Output Current | 630mA | |
Depth | 61mm | |
Width | 18mm | |
Height | 90mm | |
Standards Met | CE | |
Model | STEP3-PS/1AC/24DC/0.63/PT | |
Ripple And Noise | 100mV Pk-Pk | |
Maximum Temperature | +70°C | |
MTBF | 3500000h | |
Minimum Temperature | -10°C | |
Mounting Type | DIN Rail | |
Efficiency | 87% | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Series STEP POWER | ||
Type Switched Mode | ||
Electrical Phase 1 | ||
AC or DC Input Voltage ac | ||
Input Voltage 100 → 240 V, 110 → 250 V | ||
AC or DC Output Voltage dc | ||
Output Voltage 24V dc | ||
Output Current 630mA | ||
Depth 61mm | ||
Width 18mm | ||
Height 90mm | ||
Standards Met CE | ||
Model STEP3-PS/1AC/24DC/0.63/PT | ||
Ripple And Noise 100mV Pk-Pk | ||
Maximum Temperature +70°C | ||
MTBF 3500000h | ||
Minimum Temperature -10°C | ||
Mounting Type DIN Rail | ||
Efficiency 87% | ||
- COO (Country of Origin):
- VN
Phoenix Contact STEP3 Series PSU, 630mA Output Current - 1088495
This high-traffic power supply unit from Phoenix Contact is a reliable solution for various applications. The unit offers an energy-efficient power supply with AC to DC conversion, ensuring stable power output. Ideal for intelligent building automation, this power supply provides a flexible and space-saving option. With input voltage range from 100 to 240V and output current of 630mA at 24V, this power supply is designed for professional use in automation and control systems.
Features & Benefits
• Efficient AC to DC power conversion for reliable performance
• Wide input voltage range of 100-240V for versatile application
• Output voltage of 24V ensures stable power supply for connected devices
• High output current of 630mA for powering multiple devices simultaneously
• Wide input voltage range of 100-240V for versatile application
• Output voltage of 24V ensures stable power supply for connected devices
• High output current of 630mA for powering multiple devices simultaneously
Applications
• Ideal for use in control cabinets, industrial automation, and intelligent building systems
Can it handle a voltage range of 100-240V?
Yes, it is designed to handle a voltage range of 100-240V.
Is it suitable for powering multiple devices simultaneously?
Yes, with an output current of 630mA, this power supply can power multiple devices.
Will it provide a stable 24V output voltage?
Yes, this power supply ensures a stable 24V output voltage for connected devices.
