RS PRO Switched Mode DIN Rail Power Supply, 187 → 550 V ac / 250 → 725V dc ac Input, 48V dc dc Output,
- RS Stock No.:
- 192-7578
- Brand:
- RS PRO
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 192-7578
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Series | Compact | |
Type | Switched Mode | |
Electrical Phase | 3 | |
AC or DC Input Voltage | ac | |
Input Voltage | 187 → 550 V ac / 250 → 725V dc | |
AC or DC Output Voltage | dc | |
Output Voltage | 48V dc | |
Output Current | 10A | |
Dimensions | 73 x 140 x 150mm | |
Width | 73mm | |
Height | 140mm | |
Depth | 144.5mm | |
Ripple And Noise | <100 mV pp | |
MTBF | 500000h | |
Efficiency | 92% | |
Minimum Temperature | -40°C | |
Maximum Temperature | +70°C | |
Mounting Type | DIN Rail Mount | |
Load Regulation | 1% | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Series Compact | ||
Type Switched Mode | ||
Electrical Phase 3 | ||
AC or DC Input Voltage ac | ||
Input Voltage 187 → 550 V ac / 250 → 725V dc | ||
AC or DC Output Voltage dc | ||
Output Voltage 48V dc | ||
Output Current 10A | ||
Dimensions 73 x 140 x 150mm | ||
Width 73mm | ||
Height 140mm | ||
Depth 144.5mm | ||
Ripple And Noise <100 mV pp | ||
MTBF 500000h | ||
Efficiency 92% | ||
Minimum Temperature -40°C | ||
Maximum Temperature +70°C | ||
Mounting Type DIN Rail Mount | ||
Load Regulation 1% | ||
- COO (Country of Origin):
- TW
RS PRO 480W Compact Universal 3 Phase DIN Rail Power Supply (TS35)
A highly efficient compact universal 3 phase power supply with Power Fact Correction (PFC) . Designed for mounting on 35mm DIN rails the power supply is simple to install and integrate into existing set ups and is connected by screw terminals.
A regulated primary switch mode power supply with a N/O contact arrangement and a wide input range of 187–550 Vac, 250–725 Vdc
The DIN rail power supply features short circuit and over voltage protection contained within a robust Aluminium housing fit for industrial use.
Features and Benefits
3 phase switched power supply
Power Factor Correction (PFC)
Universal power supply
Wide input range of 187 - 550 Vac/ 250 - 725Vdc
48V adjustable output
Regulated
Over Voltage protection
Over Temperature protection
Short circuit protection
Aluminium housing
TS35 DIN rail mounting
Screw terminals
Dimensions of 73 x 140 x 150mm
Standards and Approvals: UL 580C, IEC 950,EN 60950, EN 61000-6-2, EN 61000-6-4, EN 55011, EN 61000-4-2, EN 61000-4-2/3/4/5/6/11
What is a DIN Rail Power Supply?
A DIN rail mounting power supply is also known as an electric power converter. A convenient option when it comes to powering DC operated equipment. The power supply is mounted on a standard-sized metal strip (35 mm) to which electronic devices such as circuit breakers, relays, motor starters, and PLCs can be mounted enabling the assembly of very compact systems.
Why would you need these power supplies?
RS PRO DIN power supplies are the ideal solution for critical applications. These compact devices present excellent durability and safety when it comes to powering your products and includes features such as adjustable outputs used to compensate for voltage drop.
Why RS PRO?
RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
