Schneider Electric Switch Mode DIN Rail Power Supply, 100 → 240V ac ac Input, 48V dc dc Output, 3A Output, 120W
- RS Stock No.:
- 146-799
- Mfr. Part No.:
- ABL7RP4803
- Brand:
- Schneider Electric
Discontinued
- RS Stock No.:
- 146-799
- Mfr. Part No.:
- ABL7RP4803
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Type | Switch Mode | |
| Electrical Phase | 1, 2 | |
| Number of Outputs | 1 | |
| AC or DC Input Voltage | ac | |
| Input Voltage | 100 → 240V ac | |
| AC or DC Output Voltage | dc | |
| Output Voltage | 48V dc | |
| Output Current | 3A | |
| Dimensions | 120 x 54 x 120mm | |
| Depth | 120mm | |
| Height | 120mm | |
| Width | 54mm | |
| Maximum Temperature | +70°C | |
| Ripple And Noise | 200mV | |
| Mounting Type | DIN Rail Mount | |
| Load Regulation | ±3% | |
| Minimum Temperature | 0°C | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Type Switch Mode | ||
Electrical Phase 1, 2 | ||
Number of Outputs 1 | ||
AC or DC Input Voltage ac | ||
Input Voltage 100 → 240V ac | ||
AC or DC Output Voltage dc | ||
Output Voltage 48V dc | ||
Output Current 3A | ||
Dimensions 120 x 54 x 120mm | ||
Depth 120mm | ||
Height 120mm | ||
Width 54mm | ||
Maximum Temperature +70°C | ||
Ripple And Noise 200mV | ||
Mounting Type DIN Rail Mount | ||
Load Regulation ±3% | ||
Minimum Temperature 0°C | ||
- COO (Country of Origin):
- CN
Schneider Electric DIN Rail Power Supplies - Phaseo ABL8 Series
The new generation of Schneider Electric DIN Rail Power supplies, specifically the ABL8 series, brings a new meaning to your automated systems. The ingenuity of the ABL8 means you have greater control of your systems via the use of several function modules. The modular nature of the DIN Rail device is designed for simple machines/applications. Compact in nature but high efficiency means these power supplies have several industrial applications.
Features & benefits
• Advanced LED diagnostics for status.
- 1 x LED green for output voltage.
- 1 x LED orange for input voltage.
(see datasheet for model-specific details)
• DIN-Rail mounting support. Screw terminal connection support. Easily mounted/snapped onto existing metal rails.
Protection Ratings & Safety Features
• Modules are fitted with automatic electronic reset protection against short circuits & over-voltage.
• IP20 rated conforming to EN/IEC 60529.
• Class 1 protection against electric shock (conforming to VDE 0106-1)
• RoHS EUR compliant.
• IP20 rated conforming to EN/IEC 60529.
• Class 1 protection against electric shock (conforming to VDE 0106-1)
• RoHS EUR compliant.
Applications
Perfect as a central unit for power distribution, the DIN Rail Power Supply can be used in several different scenarios, including:
• Industrial control units/instrumentation.
• Automation applications.
• Commercial buildings for lighting etc.
• Industrial control units/instrumentation.
• Automation applications.
• Commercial buildings for lighting etc.
