RS PRO DC Socket Rated At 2.0A, 18.0 V, Panel Mount, length 14.5mm, Silver
- RS Stock No.:
- 294-7018
- Mfr. Part No.:
- 4840.2231
- Brand:
- NEUTRAL
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Pack of 5)
£2.842
(exc. VAT)
£3.41
(inc. VAT)
- RS Stock No.:
- 294-7018
- Mfr. Part No.:
- 4840.2231
- Brand:
- NEUTRAL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NEUTRAL | |
| DC Power Connector Type | DC Socket | |
| Current Rating | 2.0A | |
| Body Orientation | Straight | |
| Voltage Rating | 18.0 V | |
| Length | 14.5mm | |
| Width | 14.25mm | |
| Mounting Type | Panel Mount | |
| Pin Diameter | 1.45mm | |
| Contact Plating | Silver | |
| Contact Material | Brass | |
| Series | JSBJ5 | |
Select all | ||
|---|---|---|
Brand NEUTRAL | ||
DC Power Connector Type DC Socket | ||
Current Rating 2.0A | ||
Body Orientation Straight | ||
Voltage Rating 18.0 V | ||
Length 14.5mm | ||
Width 14.25mm | ||
Mounting Type Panel Mount | ||
Pin Diameter 1.45mm | ||
Contact Plating Silver | ||
Contact Material Brass | ||
Series JSBJ5 | ||
