TRACOPOWER TMV 2HI DC-DC Converter, 12V dc/ 168mA Output, 4.5 → 5.5 V dc Input, 2W, Through Hole, +80°C Max Temp

RS Stock No.:: 898-7028
Mfr. Part No.:: TMV 2-0512SHI
Brand:: TRACOPOWER

TRACOPOWER TMV 2HI DC-DC Converter, 12V dc/ 168mA Output, 4.5 → 5.5 V dc Input, 2W, Through Hole, +80°C Max Temp

Available to back order for despatch when stock is available

Price Each

£9.70

(exc. VAT)

£11.64

(inc. VAT)

Units	Per unit
1 - 4	£9.70
5 - 9	£9.42
10 - 24	£9.12
25 - 49	£8.73
50 +	£8.34

RS Stock No.:: 898-7028
Mfr. Part No.:: TMV 2-0512SHI
Brand:: TRACOPOWER

Datasheet
Industrial Power Solutions Catalogue
Selection Guide

Attribute	Value
Output Voltage	12V dc
Input Voltage Range	4.5 → 5.5 V dc
Power Rating	2W
Input Voltage Nominal	5 V dc
Output Current	168mA
Mounting Type	Through Hole
Isolated	Yes
Number of Outputs	1
Output Voltage Adjustment Range	±5%
Package	SIP 7
Isolation Voltage	5.2kV dc
Length	19.5mm
Width	7.1mm
Depth	10.2mm
Series	TMV 2HI
Load Regulation	<10%
Efficiency	77%
Minimum Temperature	-40°C
Maximum Temperature	+80°C
Standards Met	A1:2010, A1:2011, A11:2009, A12:2011, Am 1:2009, ANSI/UL No. 60950-1 2nd ed., CAN/CSA-C22.2 No 60950-1-07 2nd ed, CB, cSAus, EN 60950-1:2006, IEC 60950-1:2005 (2nd edition), REACH, ROHS

TRACOPOWER TMV 2HI DC-DC Converter, 12V dc/ 168mA Output, 4.5 → 5.5 V dc Input, 2W, Through Hole, +80°C Max Temp

Traco 2W SIP Unregulated Isolated DC-DC Converter - TMV 2HI Series
