TRACOPOWER TMR 12WI DC-DC Converter, 5V dc/ 1.2A Output, 4.5 → 18 V dc Input, 12W, PCB Mount, +85°C Max Temp
- RS Stock No.:
- 251-7271
- Mfr. Part No.:
- TMR 12-1221WI
- Brand:
- TRACOPOWER
Bulk discount available
Subtotal (1 unit)*
£32.05
(exc. VAT)
£38.46
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 9 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £32.05 |
| 5 - 9 | £31.09 |
| 10 - 24 | £30.13 |
| 25 - 49 | £28.85 |
| 50 + | £27.56 |
*price indicative
- RS Stock No.:
- 251-7271
- Mfr. Part No.:
- TMR 12-1221WI
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Output Voltage | 5V dc | |
| Input Voltage Range | 4.5 → 18 V dc | |
| Power Rating | 12W | |
| Input Voltage Nominal | 12 V DC | |
| Output Current | 1.2A | |
| Mounting Type | PCB Mount | |
| Isolated | Yes | |
| Number of Outputs | 2 | |
| Output Voltage Adjustment Range | -5 → +5V dc | |
| Package | SIP 8 | |
| Isolation Voltage | 1.2kV dc | |
| Length | 22mm | |
| Depth | 12mm | |
| Width | 9.6mm | |
| Series | TMR 12WI | |
| Railway Approved | No | |
| Load Regulation | 1% | |
| Maximum Temperature | +85°C | |
| Medical Approved | No | |
| Efficiency | 86% | |
| Minimum Temperature | -40°C | |
| Standards Met | RoHS | |
Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Output Voltage 5V dc | ||
Input Voltage Range 4.5 → 18 V dc | ||
Power Rating 12W | ||
Input Voltage Nominal 12 V DC | ||
Output Current 1.2A | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range -5 → +5V dc | ||
Package SIP 8 | ||
Isolation Voltage 1.2kV dc | ||
Length 22mm | ||
Depth 12mm | ||
Width 9.6mm | ||
Series TMR 12WI | ||
Railway Approved No | ||
Load Regulation 1% | ||
Maximum Temperature +85°C | ||
Medical Approved No | ||
Efficiency 86% | ||
Minimum Temperature -40°C | ||
Standards Met RoHS | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
TRACOPOWER TMR 12WI Series DC-DC Converter, 86 % Efficiency, 4.5 to 18 V DC Input Voltage Range - TMR 12-1221WI
This DC-DC converter by TRACOPOWER is a high-quality 12W converter in an SIP-8 metal casing, providing a regulated output with a 5V output voltage. With wide input voltage ranges and high efficiency, this converter is ideal for various applications.
Features & Benefits
• Ultra-compact 12W converter in SIP-8 metal casing
• Wide 4:1 input voltage ranges for versatile usage
• High efficiency of up to 90% for low thermal loss
• Regulated 5V output voltage for consistent performance
• Remote on/off control for added convenience
• Wide 4:1 input voltage ranges for versatile usage
• High efficiency of up to 90% for low thermal loss
• Regulated 5V output voltage for consistent performance
• Remote on/off control for added convenience
Applications
• Ideal for use in communication equipment, industrial electronics, and instrumentation
• Suitable for space-critical applications due to compact dimensions
• Can be used for applications requiring isolated DC-DC conversion
• Suitable for space-critical applications due to compact dimensions
• Can be used for applications requiring isolated DC-DC conversion
Can it be used in industrial electronics applications?
Yes, this DC-DC converter is ideal for industrial electronics due to its high efficiency and regulated output.
Will it work for communication equipment?
Yes, the converter is suitable for use in communication equipment, providing stable 5V output.
Is it suitable for space-critical applications?
Yes, the ultra-compact dimensions make it reliable for space-critical applications where size is a constraint.
