Molex Female Crimp Terminal, SMT Termination

View all Crimp Contacts

Subtotal (1 tray of 252 units)*

£1,205.064

(exc. VAT)

£1,445.976

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 999,999,756 unit(s) shipping from 13 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tray*
252 +£4.782£1,205.06

*price indicative

An image of a Molex Crimp Tool
Molex Logo
The Perfect Pair: Contacts & Crimp Tools
Complete your connection kit with the full Molex solution!
Shop Molex Crimp Tools here!
RS Stock No.:
189-5724
Mfr. Part No.:
204318-0006
Brand:
Molex
Find similar products by selecting one or more attributes.
Select all

Brand

Molex

Gender

Female

For Use With

CST High-Current Interconnect System

Termination Method

SMT

Contact Plating

Gold, Silver

Contact Material

Copper Alloy

Series Number

204318

Maximum Contact Resistance

0.2mΩ

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+105°C

COO (Country of Origin):
MY
Coeur CST High-Current Female Surface Mount Socket, 6.00mm Diameter.

Touch-safe feature
Positive latching
Vertical, PC, bus bar-mounting header
Keyed
Terminal retention housings- Locks in contacts
1/0 AWG crimp contacts- For 8.0mm form factor
Fully shrouded female and male contacts- Is touch safe and offers 600V rating in configuration shown above
Male pin has minimal protrusion above the socket housing when mated- Saves space above the PCB or bus bar
2-circuit, 8.00mm version shown is currently available.
Pick-and-place cap on SMT Sockets- Enables automated SMT socket placement to PCB
Applications
Data/Computing
Routers
Networking
Storage
Telecommunications/Networking
Servers
Storage
Industrial
Power Supply
Data Centers
Servers
Data Storage
PDU
UPS/Battery Storage
Switches
Circuit Breakers
Instrumentation
