Two unscreened and geometrically coded flat cores (1.5mm²) transmit power and data with the conductors, achieved by 'vampire' clamping devices located within the control unit and peripheral modules
Developed specifically for use at the lowest field bus levels - binary sensors and actuators
Rubber insulated version is suitable for use in dry and damp interiors with a low mechanical and chemical stress
TPE insulated version is suitable for use in wet industrial environments with high mechanical and chemical stress, such as automotive production where cooling lubricants may be mixed with water
Yellow (RAL 1023) outer sheath denotes standard data and power use
Black (RAL 9005) outer sheath denotes 24V dc auxiliary power use
Conductor resistance: 27.4Ω/km
AS-I is a European Standard in accordance with EN 50295

UL, CSA

This data cable by Lapp is a versatile and high-quality solution for various applications in the field of automation, electronics, electrical, and mechanical industries. With features like TPE insulation, multicore design, tinned copper conductor, UNITRONIC BUS ASI series compatibility, and more, this cable provides reliable performance and durability.

• TPE insulation ensures safety and protection for the cable
• Multicore design allows for efficient data transmission
• Tinned copper conductor provides excellent conductivity
• UNITRONIC BUS ASI compatibility ensures seamless integration into existing systems
• Halogen-free design for enhanced safety measures
• Oil resistance for added durability
• 15 AWG cable for optimal power distribution
• 300V voltage rating for reliable performance

• Ideal for use in AS-INTERFACE systems
• Suitable for fixed installations in dry and damp environments
• Can be used for flexible applications without tensile stress

Yes, the cable version with a black outer sheath can be used outdoors.

Yes, it is oil resistant, making it suitable for harsh environments.

Yes, this cable is specifically designed to work with UNITRONIC BUS ASI systems.

It has a temperature range of -30°C up to +85°C, making it suitable for various operating conditions.

Yes, this cable conforms to the EU Directive 2011/65/EU, ensuring compliance with RoHS standards.

LAPP Industrial Cable

IBS cables for industrial communications and field bus in sensors / actuators.

• Peak working voltage 250V (not for power purposes)
• Test Voltage 1500V
• Temperature range -40°C to +80°C
