ABB AF Contactor, 230V ac Coil, 3-Pole, 9 A, 4 kW, 3 NO, 690V ac
- RS Stock No.:
- 711-6174
- Distrelec Article No.:
- 304-22-303
- Mfr. Part No.:
- 1SBL137001R1301 AF09-30-01-13
- Brand:
- ABB
Subtotal (1 unit)*
£36.90
(exc. VAT)
£44.28
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 43 unit(s) shipping from 05 October 2026
- Plus 35 unit(s) shipping from 05 October 2026
- Plus 40 unit(s) shipping from 22 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £36.90 |
*price indicative
- RS Stock No.:
- 711-6174
- Distrelec Article No.:
- 304-22-303
- Mfr. Part No.:
- 1SBL137001R1301 AF09-30-01-13
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Coil Voltage | 230V ac | |
| Product Type | Contactor | |
| Number of Poles | 3 | |
| Contact Voltage | 690V ac | |
| Contact Current | 9A | |
| Series | AF | |
| Power Rating | 4kW | |
| Mount Type | DIN Rail | |
| Function | Motor Control | |
| Normal State Configuration | 3 NO | |
| Number of Auxiliary Contacts | 1 | |
| Auxiliary Contact Configuration | 1 NC | |
| Terminal Type | Screw | |
| Operational Current Ie | 25A | |
| Contactor Application | Motor Control | |
| Control Circuit Voltage Uc | 130V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 70°C | |
| Length | 86mm | |
| Standards/Approvals | IEC 60947-4-1 | |
| Width | 45mm | |
| Depth | 77mm | |
| Pole and Throw Configuration | 3P | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Coil Voltage 230V ac | ||
Product Type Contactor | ||
Number of Poles 3 | ||
Contact Voltage 690V ac | ||
Contact Current 9A | ||
Series AF | ||
Power Rating 4kW | ||
Mount Type DIN Rail | ||
Function Motor Control | ||
Normal State Configuration 3 NO | ||
Number of Auxiliary Contacts 1 | ||
Auxiliary Contact Configuration 1 NC | ||
Terminal Type Screw | ||
Operational Current Ie 25A | ||
Contactor Application Motor Control | ||
Control Circuit Voltage Uc 130V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 70°C | ||
Length 86mm | ||
Standards/Approvals IEC 60947-4-1 | ||
Width 45mm | ||
Depth 77mm | ||
Pole and Throw Configuration 3P | ||
ABB Contactor, 50/60Hz Rated Frequency, NEMA Size 00 - AF Series - 1SBL137001R1301 AF09-30-01-13
Get your motor running with this contactor from ABB. It has a wide control voltage range between 100 and 250V DC, so it's a versatile option. The unit also takes surges in its stride, thanks to built-in surge protection. A 3NO configuration allows for the control of three separate circuits, which stay off by default and only switch on when the contactor is energised. This enhances safety and system flexibility by ensuring circuits aren't active until you deliberately switch them on.
• Compact dimensions of 45 (W) x 77 (L) x 86mm (H) save space in your enclosure
• Mounts on a standard 35mm DIN rail for installation in a jiffy
• Broad operating temperature range between -40°C and +70°C for use in demanding settings
Applications
• Automotive industry
• Marine machinery
• Manufacturing facilities
What's the maximum electrical switching frequency of this component?
The contactor handles 1,200 cycles per hour, so it has the ability to rapidly switch circuits on and off. This makes it suitable for applications – like motors – that need frequent or high-speed switching.
