Schneider Electric TeSys K LC1K Contactor, 230 V ac Coil, 4-Pole, 20 A, 2NO + 2NC, 690 V ac
- RS Stock No.:
- 609-0172
- Mfr. Part No.:
- LC1K09008P7
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£36.40
(exc. VAT)
£43.68
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 16 unit(s) ready to ship
- Plus 19 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £36.40 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 609-0172
- Mfr. Part No.:
- LC1K09008P7
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Coil Voltage | 230 V ac | |
| Number of Poles | 4 | |
| Contact Voltage Rating | 690 V ac | |
| Contact Current Rating | 20 A | |
| Series | LC1K | |
| Range | TeSys K | |
| Function | Reversing | |
| Normal State Configuration | 2NO + 2NC | |
| Terminal Type | Screw | |
| Length | 45mm | |
| Width | 58mm | |
| Depth | 57mm | |
| Better World Verification | Green Premium | |
| Better World Product | Yes | |
| Maximum Operating Temperature | +50°C | |
| Minimum Operating Temperature | -25°C | |
Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Coil Voltage 230 V ac | ||
Number of Poles 4 | ||
Contact Voltage Rating 690 V ac | ||
Contact Current Rating 20 A | ||
Series LC1K | ||
Range TeSys K | ||
Function Reversing | ||
Normal State Configuration 2NO + 2NC | ||
Terminal Type Screw | ||
Length 45mm | ||
Width 58mm | ||
Depth 57mm | ||
Better World Verification Green Premium | ||
Better World Product Yes | ||
Maximum Operating Temperature +50°C | ||
Minimum Operating Temperature -25°C | ||
- COO (Country of Origin):
- FR
Schneider Electric LC1K Series Contactor, 20A Current Rating, 230V AC Coil Voltage - LC1K09008P7
This contactor is an essential component for industrial and automation applications, designed to manage high electrical loads effectively. The TeSys K series contactor, featuring a 230V AC coil and capable of handling up to 20A, ensures reliable performance under various conditions. With dimensions of 58mm in width, 45mm in length, and 57mm in depth, it is easily mountable on a DIN rail, optimising space in control panels.
Features & Benefits
• Designed for reversing operations, enhancing operational flexibility
• 4-pole configuration with 2 normally open and 2 normally closed contacts
• Rated for 690V AC with a 20A contact current capability
• Screw terminal connections allow for secure and versatile wiring options
• Operates within a temperature range of -25°C to +50°C for diverse environments
• Mechanical and electrical durability ensures longevity and reliability
• 4-pole configuration with 2 normally open and 2 normally closed contacts
• Rated for 690V AC with a 20A contact current capability
• Screw terminal connections allow for secure and versatile wiring options
• Operates within a temperature range of -25°C to +50°C for diverse environments
• Mechanical and electrical durability ensures longevity and reliability
Applications
• Used for controlling resistive loads in industrial
• Employed in automation systems requiring precise load management
• Suitable for lighting control and motor management systems
• Utilised in equipment where safe and reliable operation is paramount
• Employed in automation systems requiring precise load management
• Suitable for lighting control and motor management systems
• Utilised in equipment where safe and reliable operation is paramount
What is the inrush power rating for this device?
The inrush power is rated at 30 VA when operated at 20°C, ensuring efficient performance during startup.
What is the maximum operational rate for this contactor?
It supports a maximum operating rate of 3600 cycles per hour, making it suitable for high-frequency applications.
How does the contactor accommodate different cable types?
It can fit various cable sizes, accommodating solid and flexible cables ranging from 0.34mm² to 4mm² for versatile installation.
What are the implications of the operational temperature range?
The operating temperature range of -25°C to +50°C allows for versatile usage in differing environmental conditions without compromising performance.
What electrical standards does this contactor comply with?
This product meets several standards, including EN/IEC 60947-4-1, ensuring reliability and safety in electrical installations.
