ABB ESB40-20-230VAC/DC ESB Contactor, 2-Pole, 40 A, 9.2 kW, 2NO, 230 V ac
- RS Stock No.:
- 183-3660
- Mfr. Part No.:
- GHE3491402R0006
- Brand:
- ABB
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 183-3660
- Mfr. Part No.:
- GHE3491402R0006
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Number of Poles | 2 | |
| Contact Voltage Rating | 230 V ac | |
| Contact Current Rating | 40 A | |
| Range | ESB40-20-230VAC/DC | |
| Power Rating | 9.2 kW | |
| Series | ESB | |
| Normal State Configuration | 2NO | |
| Width | 65mm | |
| Length | 54mm | |
| Depth | 85mm | |
| Minimum Operating Temperature | -25°C | |
| Mounting Style | DIN Rail Mount | |
| Maximum Operating Temperature | +55°C | |
Select all | ||
|---|---|---|
Brand ABB | ||
Number of Poles 2 | ||
Contact Voltage Rating 230 V ac | ||
Contact Current Rating 40 A | ||
Range ESB40-20-230VAC/DC | ||
Power Rating 9.2 kW | ||
Series ESB | ||
Normal State Configuration 2NO | ||
Width 65mm | ||
Length 54mm | ||
Depth 85mm | ||
Minimum Operating Temperature -25°C | ||
Mounting Style DIN Rail Mount | ||
Maximum Operating Temperature +55°C | ||
- COO (Country of Origin):
- DE
The ESB40 installation contactor is a 2 pole contactor suitable for modular switchboards. They are specially designed fitting to modular DIN rail products and for applications where customers want to use the panel design with high finger protection. Installation contactors are used in residential, commercial and industrial applications for the control of single or three-phase loads up to 40 A or switching of control signals. Further features are the noiseless and hum-free DC coil, the integrated overvoltage protection up to 5 kV and a switch position indication. Auxiliary contacts, distance pieces and sealing cover for protection against unauthorized changes are available as accessory.
