Schneider Electric, TeSyS LR Thermal Overload Relay 1 NO/1 NC, 5.5A, 8 A F.L.C, 6A Contact Rating, 2 W
- RS Stock No.:
- 256-6658
- Mfr. Part No.:
- LR7K0314
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£112.10
(exc. VAT)
£134.52
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1 unit(s) shipping from 27 April 2026
- Plus 3 unit(s) shipping from 29 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £112.10 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 256-6658
- Mfr. Part No.:
- LR7K0314
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| FLC Motor Rating | 5.5, 8A | |
| Product Type | Thermal Overload Relay | |
| Relay Contact Current | 6A | |
| Mount Type | Rail, Plate | |
| Series | TeSyS LR | |
| Power Rating | 2W | |
| Normal State Configuration | 1 NO/1 NC | |
| Terminal Type | Screw Clamp | |
| Reset Method | Push Button or Electric | |
| IP Rating | IP2X | |
| Width | 45mm | |
| Number of Auxiliary Contacts | 2 | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 55°C | |
| Length | 58mm | |
| Depth | 65mm | |
| Standards/Approvals | BS 4941 NF C 63-650 VDE 0660 IEC 60947 | |
| Better World Product | Yes | |
| Supply Voltage | 690V ac | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
FLC Motor Rating 5.5, 8A | ||
Product Type Thermal Overload Relay | ||
Relay Contact Current 6A | ||
Mount Type Rail, Plate | ||
Series TeSyS LR | ||
Power Rating 2W | ||
Normal State Configuration 1 NO/1 NC | ||
Terminal Type Screw Clamp | ||
Reset Method Push Button or Electric | ||
IP Rating IP2X | ||
Width 45mm | ||
Number of Auxiliary Contacts 2 | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 55°C | ||
Length 58mm | ||
Depth 65mm | ||
Standards/Approvals BS 4941 NF C 63-650 VDE 0660 IEC 60947 | ||
Better World Product Yes | ||
Supply Voltage 690V ac | ||
- COO (Country of Origin):
- CZ
The Schneider Electric non differential thermal overload relay for protection of 3-phase motors. Non differential device, it can be used with unbalanced loads. It provides a thermal adjustment dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons and a flag indicator. Settings are protected by a transparent cover lockable by sealing.
Easy to separate
Designed for simple control systems
Relay trip indicator to facilitate motor status monitoring
