Siemens 3RB Overload Relay 1NC/1NO, 80 A F.L.C, 4 A Contact Rating, 75 kW, 3P, SIRIUS
- RS Stock No.:
- 252-3242
- Mfr. Part No.:
- 3RB30362WX1
- Brand:
- Siemens
Subtotal (1 unit)*
£228.27
(exc. VAT)
£273.92
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 11 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £228.27 |
*price indicative
- RS Stock No.:
- 252-3242
- Mfr. Part No.:
- 3RB30362WX1
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| FLC Motor Rating | 80 A | |
| Contact Current Rating | 4 A | |
| Range | SIRIUS | |
| Pole Configuration | 3P | |
| Series | 3RB | |
| Power Rating | 75 kW | |
| Normal State Configuration | 1NC/1NO | |
Select all | ||
|---|---|---|
Brand Siemens | ||
FLC Motor Rating 80 A | ||
Contact Current Rating 4 A | ||
Range SIRIUS | ||
Pole Configuration 3P | ||
Series 3RB | ||
Power Rating 75 kW | ||
Normal State Configuration 1NC/1NO | ||
- COO (Country of Origin):
- CZ
The Siemens Overload is used for motor protection. The relay have current capacity of relay 20 to 80 A. It has size S2, class 20E stand-alone installation main circuit, straight-through transformer auxiliary circuit and it is spring-type terminal manual-automatic-reset device.
Surge voltage resistance rated value of 6 kV
Shock resistance 15g / 11 ms
Operating frequency rated value 50 to 60 Hz
Power loss: 0.2 W
Shock resistance 15g / 11 ms
Operating frequency rated value 50 to 60 Hz
Power loss: 0.2 W
