Schneider Electric, TeSyS LR Thermal Overload Relay 1 NO/1 NC, 115A, 28 A F.L.C, 115A, 28 A Contact Rating, 250V dc
- RS Stock No.:
- 249-4782
- Mfr. Part No.:
- LR9G115
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£251.00
(exc. VAT)
£301.20
(inc. VAT)
FREE delivery for orders over £60.00
- 7 unit(s) ready to ship
- Plus 3 unit(s) ready to ship from another location
Units | Per unit |
|---|---|
| 1 + | £251.00 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 249-4782
- Mfr. Part No.:
- LR9G115
- Brand:
- Schneider Electric
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| FLC Motor Rating | 115, 28A | |
| Product Type | Thermal Overload Relay | |
| Relay Contact Current | 115, 28A | |
| Series | TeSyS LR | |
| Mount Type | Plate | |
| Normal State Configuration | 1 NO/1 NC | |
| Terminal Type | Busbar | |
| IP Rating | IP2X | |
| Reset Method | Automatic | |
| Adjustable Current Range | 28 to 115 A | |
| Minimum Operating Temperature | -25°C | |
| Width | 105mm | |
| Contact Voltage | 250V dc | |
| Maximum Operating Temperature | 60°C | |
| Length | 400mm | |
| Standards/Approvals | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 | |
| Depth | 126mm | |
| Better World Product | Yes | |
| Supply Voltage | 1000V ac | |
| Control Voltage | 250V dc | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
FLC Motor Rating 115, 28A | ||
Product Type Thermal Overload Relay | ||
Relay Contact Current 115, 28A | ||
Series TeSyS LR | ||
Mount Type Plate | ||
Normal State Configuration 1 NO/1 NC | ||
Terminal Type Busbar | ||
IP Rating IP2X | ||
Reset Method Automatic | ||
Adjustable Current Range 28 to 115 A | ||
Minimum Operating Temperature -25°C | ||
Width 105mm | ||
Contact Voltage 250V dc | ||
Maximum Operating Temperature 60°C | ||
Length 400mm | ||
Standards/Approvals EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 | ||
Depth 126mm | ||
Better World Product Yes | ||
Supply Voltage 1000V ac | ||
Control Voltage 250V dc | ||
- COO (Country of Origin):
- CN
