STMicroelectronics STEVAL-PCC020V1 USB → I2C/UART Bridge Evaluation Board for HVDPS STNRG011 STEVAL-PCC020V1

View this category
Bulk discount available

Subtotal (1 unit)*

£63.89

(exc. VAT)

£76.67

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible - Please check back later
Units
Per unit
1 - 4£63.89
5 - 9£62.16
10 - 24£60.53
25 - 49£58.97
50 +£57.50

*price indicative

RS Stock No.:
175-0689
Mfr. Part No.:
STEVAL-PCC020V1
Brand:
STMicroelectronics
Find similar products by selecting one or more attributes.
Select all

Brand

STMicroelectronics

Kit Classification

Evaluation Board

For Use With

HVDPS STNRG011 Programming

Featured Device

STEVAL-PCC020V1

Kit Name

STEVAL-PCC020V1 USB → I2C/UART Bridge Evaluation Board for HVDPS STNRG011

COO (Country of Origin):
IT
The STEVAL-PCC020V1 is self-supplied 5 V from the USB port. An isolated DC-DC module provides the correct supplies to the remaining electronics. The board is also able to provide the target STNRG device with a VCC voltage to program the NVM (if supply is less than 17 V).
Communication between the STEVAL-PCC020V1 and the PC is managed by a standard serial peripheral, converting the USB connection into a virtual COM port. UART RX and TX signals are then isolated with opto-couplers and connected to the STM32 microcontroller, so the USB port and the rest of the board remain isolated from the mains.

Bidirectional communication between PC (USB) and STNRG011
Self-powered from the USB line
On-board 19 V generation for STNRG011 programming
Electric Isolation between USB and other board electronics
UART and I²C bus muxed together on the same interface
On-board firmware upgrade through USB port
Display power metrics (AC voltage, PFC power)
