- RS Stock No.:
- 906-0644
- Brand:
- RS PRO
80 In stock - FREE next working day delivery available
4 available from Europe for delivery within 1 working day(s).
Added
Price 1 Reel of 100 Metre(s)
£248.92
(exc. VAT)
£298.70
(inc. VAT)
Reel(s) | Per Reel | Per Metre* |
1 + | £248.92 | £2.489 |
*price indicative |
- RS Stock No.:
- 906-0644
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
RS PRO Black unterminated to unterminated coaxial cable
From the trusted brand RS PRO, comes a range of high quality RG316 unterminated to unterminated coaxial cables. Constructed out of industry-standard components, these flexible cables have been designed so that the user can attach connection points on each end.
Coaxial type cables are designed to carry signals over long distances and are easy to install.
Coaxial type cables are designed to carry signals over long distances and are easy to install.
Features and benefits
- Strong brown FEP (Fluorinated Ethylene Propylene) jacket
- Silver copper braiding
- Impedance of 50 ohms
Applications
Coaxial cables are primarily used by electricians and IT personnel and have a range of application use such as;
- Connecting radio transmitters and receivers with their antennas
- Computer network (Internet) connections
- Feeding satellite signals through to your TV.
What is Impedance?
Impedance is an electric currents opposition being measured when the voltage has been applied.
Why choose RS PRO?
RS PRO is our own brand of high-quality products whilst bringing you great value for money. Our wide range of products have been engineered to meet high industry standards, so you are ensured reliable and robust solutions.
Specifications
Attribute | Value |
---|---|
Terminated/Unterminated | Unterminated |
Coaxial Type | RG316 |
Outer Diameter | 2.5mm |
CPR Certification | Fca |
Characteristic Impedance | 50 Ω |
Attenuation | 96 dB @ 1000 MHz |
Length | 100m |
Sheath Colour | Brown |
Conductor Strand Type | Stranded |
Sheath Material | FEP |
Shielding | Silver Plated Copper Braid |
Number of Strands | 7 |
Operating Temperature Range | -50 → +200 °C |
Maximum Operating Temperature | +200°C |
Size of Strands | 0.17 mm |
Conductor Material | Silver Plated Copper Clad Steel |
Capacitance | 95pF/m |
Minimum Operating Temperature | -50°C |
Standards Met | Euroclass Eca |
Core Strands | 7/0.17 |
Velocity ratio | 69.5% |
Insulation Material | PTFE |
