Fluke LH635 Clampmeter, 1kA dc, Max Current 600A ac CAT III 600 V
- RS Stock No.:
- 198-5817
- Mfr. Part No.:
- 60.56.52.001.0
- Brand:
- Fluke
- RS Stock No.:
- 198-5817
- Mfr. Part No.:
- 60.56.52.001.0
- Brand:
- Fluke
Select all | Attribute | Value |
|---|---|---|
| Brand | Fluke | |
| Absolute Maximum AC Current Measurement | 600A ac | |
| Absolute Maximum DC Current Measurement | 1kA dc | |
| Absolute Maximum AC Voltage Measurement | 600V ac | |
| Absolute Maximum DC Voltage Measurement | 400V dc | |
| Absolute Maximum Resistance Measurement | 4kΩ | |
| Model Number | LH635 | |
| AC Current Measurement Resolution | 100mA ac | |
| DC Current Measurement Resolution | 100mA dc | |
| Best DC Current Accuracy | ±1.3% + 3 Digits | |
| Clamp Meter Type | Continuity, Current, Diode, Resistance, Voltage | |
| Best AC Current Accuracy | ±1.3% +3 digits | |
| Best AC Voltage Accuracy | ±1% + 3 Digits | |
| Best DC Voltage Accuracy | ±1% + 3 Digits | |
| True RMS | Yes | |
| Functions Measured | AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, Resistance | |
| Height | 52mm | |
| AC Voltage Measurement Resolution | 100mV ac | |
| Minimum Operating Temperature | 0°C | |
| Dimensions | 230 x 98 x 52mm | |
| Width | 98mm | |
| Battery Type | 9V | |
| Safety Category Voltage | 600V | |
| Safety Category Level | CAT III | |
| Weight | 500g | |
| Maximum Conductor Size | 35mm | |
| DC Voltage Measurement Resolution | 100mV dc | |
| Resistance Measurement Resolution | 100mΩ | |
| Length | 230mm | |
| Power Source | Battery | |
| Display Type | LCD | |
| Battery Life | 40 h | |
| Best Resistance Measurement Accuracy | ±1% + 3 Digits | |
| Safety Category | CAT III 600 V | |
| Maximum Operating Temperature | +50°C | |
