RS PRO, 40Ω 100W Wire Wound Panel Mount Resistor ±5%

View all Chassis Mount Resistors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
185-2436
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Resistance

40Ω

Power Rating

100W

Series

RSLPR100

Package/Case

Aluminium Housed

Tolerance

±5%

Technology

Wire Wound

Termination Style

Wire Lead

Minimum Operating Temperature

-25°C

Maximum Operating Temperature

+250°C

Dimensions

100 x 75 x 5.7mm

Overall Width

75mm

Overall Height

5.7mm

Overall Length

100mm

COO (Country of Origin):
IN

RS PRO Panel Mount Resistor


The RS PRO RSLPR100 series aluminium housed panel mount resistor has a resistance of 40ohm and power rating value of 100W. Its dimensions are 100mm x 75mm x 5.7mm (L x W x H). This low profile resistor is suitable for multiple industries and applications.

Features and Benefits


• Operating temperature ranging between -25°C and 250°C
• Tolerance: ±5%
• Dielectric strength: 2500VAC-rms for 1 minute
• Minimum insulation resistance: Greater than 100Mohm

Applications


• Electrical vehicles
• Power supplies
• Control devices
• Robotics

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
