Subtotal (1 unit)*
£6.14
(exc. VAT)
£7.37
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 6 unit(s) shipping from 10 August 2026
- Plus 1,310 unit(s) shipping from 17 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £6.14 |
*price indicative
- RS Stock No.:
- 188-4656
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Current Rating | 20A | |
| Product Type | Cartridge Fuse | |
| Fuse Size | 10 x 38 mm | |
| Fuse Speed | GPV | |
| Voltage | 600V dc | |
| Overall Length | 38mm | |
| Body Material | Ceramic | |
| Fuse Characteristics | Power | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 125°C | |
| Series | K6F | |
| Diameter | 10mm | |
| Standards/Approvals | IEC 60269-6 | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Current Rating 20A | ||
Product Type Cartridge Fuse | ||
Fuse Size 10 x 38 mm | ||
Fuse Speed GPV | ||
Voltage 600V dc | ||
Overall Length 38mm | ||
Body Material Ceramic | ||
Fuse Characteristics Power | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
Series K6F | ||
Diameter 10mm | ||
Standards/Approvals IEC 60269-6 | ||
- COO (Country of Origin):
- TW
RS PRO, 20 A Ceramic Cartridge Fuse, 10 x 38 mm, Speed gPV
Use these RS PRO ceramic cartridge fuses to protect your direct current (DC) circuits. With a gPV fuse speed, voltage rating of 600 V and wide operating temperature range, they're suitable for use in many solar photovoltaic arrays. Thanks to the conductive nickel-plated copper caps and thermally stable ceramic bodies, these fuses are highly reliable.
They meet the International Electrotechnical Commission (IEC) standard 60269-6 for solar photovoltaic energy, so you can be sure they will protect your system. Renewable energy manufacturers, installers and maintenance companies use these gPV fuses. Find them in photovoltaic system panels, chargers and control systems.
Features and Benefits
• Ceramic body material
• Breaking capacity (at maximum voltage rating) of 10000 A at 600 V DC (UL248-19, IEC60269-6), 150000 A at 600 V AC (UL248-14), 50000 A at 600 V DC (UL248-14)
• Current rating of 20 A
• Fuse size of 10 (diameter) x 38 mm (length)
• gPV fuse speed
• IEC60269-6 fuse standard
• Operating temperature range of -55°C to +125°C
• Resistance of 0.004 Ω
• Voltage rating of 600 V
