Power Integrations, LNK302PNStep-Down Switching Regulator, 1-Channel 7-Pin, PDIP
- RS Stock No.:
- 525-4123
- Mfr. Part No.:
- LNK302PN
- Brand:
- Power Integrations
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Tube of 50)
£0.495
(exc. VAT)
£0.594
(inc. VAT)
- RS Stock No.:
- 525-4123
- Mfr. Part No.:
- LNK302PN
- Brand:
- Power Integrations
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Power Integrations | |
| Minimum Input Voltage | 85 V ac | |
| Maximum Input Voltage | 265 V ac | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Pin Count | 7 | |
| Package Type | PDIP | |
| Height | 3.68mm | |
| Dimensions | 9.83 x 6.6 x 3.68mm | |
| Width | 6.6mm | |
| Maximum Operating Temperature | +150 °C | |
| Minimum Operating Temperature | -40 °C | |
| Length | 9.83mm | |
Select all | ||
|---|---|---|
Brand Power Integrations | ||
Minimum Input Voltage 85 V ac | ||
Maximum Input Voltage 265 V ac | ||
Mounting Type Through Hole | ||
Number of Outputs 1 | ||
Pin Count 7 | ||
Package Type PDIP | ||
Height 3.68mm | ||
Dimensions 9.83 x 6.6 x 3.68mm | ||
Width 6.6mm | ||
Maximum Operating Temperature +150 °C | ||
Minimum Operating Temperature -40 °C | ||
Length 9.83mm | ||
LinkSwitch-TN, Power Integrations
The LinkSwitch-TN family of very low power AC-DC, Non-Isolated passive power supply replacements.
700 V Internal MOSFET Rating
Self-Powered
ON/OFF Control
Hysteretic Thermal Shutdown
Power Limiting
Frequency Jitter Reduces EMI
EcoSmart Low Standby/No-load Power Consumption
Self-Powered
ON/OFF Control
Hysteretic Thermal Shutdown
Power Limiting
Frequency Jitter Reduces EMI
EcoSmart Low Standby/No-load Power Consumption
Switching Voltage Regulators, Power Integrations
