STMicroelectronics, ST1PS03AQTR Step-Down Switching Regulator 400mA Selectable 12-Pin, 12-UFQFN
- RS Stock No.:
- 234-8889
- Mfr. Part No.:
- ST1PS03AQTR
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal (1 pack of 5 units)*
£7.52
(exc. VAT)
£9.025
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 4,055 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 5 | £1.504 | £7.52 |
| 10 - 95 | £1.474 | £7.37 |
| 100 - 245 | £1.444 | £7.22 |
| 250 - 495 | £1.416 | £7.08 |
| 500 + | £1.386 | £6.93 |
*price indicative
- RS Stock No.:
- 234-8889
- Mfr. Part No.:
- ST1PS03AQTR
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Maximum Output Current | 400mA | |
| Maximum Output Voltage | 3.3 V | |
| Regulator Function | Step Down | |
| Minimum Output Voltage | 1.6 V | |
| Minimum Input Voltage | 1.8 V | |
| Output Type | Selectable | |
| Pin Count | 12 | |
| Package Type | 12-UFQFN | |
Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Maximum Output Current 400mA | ||
Maximum Output Voltage 3.3 V | ||
Regulator Function Step Down | ||
Minimum Output Voltage 1.6 V | ||
Minimum Input Voltage 1.8 V | ||
Output Type Selectable | ||
Pin Count 12 | ||
Package Type 12-UFQFN | ||
The STMicroelectronics nano-quiescent miniaturized synchronous step-down converter, which is able to provide up to 400 mA output current with an input voltage ranging from 1.8 V to 5.5 V. This converter is specifically designed for applications where high efficiency, PCB size and thickness are the key factors.
500 nA input quiescent current at VIN = 3.6 V (not switching)
92% typical efficiency at 10 mA load (VIN = 3.6 V, VOUT = 2.5 V)
100% duty cycle
1.8 V to 5.5 V input operating range
Undervoltage lockout 1.57 V (VIN falling, typ.)
Up to 400 mA output current capability
Low power control operation for the best efficiency
Embedded soft-start circuit
Tiny external components L = 2.2 μH typical
Selectable output voltages 1.6 V to 3.3 V
Output voltage Power Good
±1.5% output voltage accuracy (VOUT, TA = 25 °C)
Dynamic output voltage selection (D0, D1 and D2)
Load switch controlled by AUX input
Available in TQFN12 package
92% typical efficiency at 10 mA load (VIN = 3.6 V, VOUT = 2.5 V)
100% duty cycle
1.8 V to 5.5 V input operating range
Undervoltage lockout 1.57 V (VIN falling, typ.)
Up to 400 mA output current capability
Low power control operation for the best efficiency
Embedded soft-start circuit
Tiny external components L = 2.2 μH typical
Selectable output voltages 1.6 V to 3.3 V
Output voltage Power Good
±1.5% output voltage accuracy (VOUT, TA = 25 °C)
Dynamic output voltage selection (D0, D1 and D2)
Load switch controlled by AUX input
Available in TQFN12 package
