4 Hole , FYC 60 TF, 60mm ID
- RS Stock No.:
- 212-4579
- Mfr. Part No.:
- FYC 60 TF
- Brand:
- SKF
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 212-4579
- Mfr. Part No.:
- FYC 60 TF
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 60mm | |
| Number of Mount Holes | 4 | |
| Length | 195mm | |
| Width | 68.7mm | |
| Depth | 56.7mm | |
Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 60mm | ||
Number of Mount Holes 4 | ||
Length 195mm | ||
Width 68.7mm | ||
Depth 56.7mm | ||
- COO (Country of Origin):
- IT
The SKF FY housing shape (Y-bearing) ball bearing units consist of an insert bearing mounted in a housing which can be bolted to support surface. The insert bearing unit has 60mm inside diameter and 195mm overall length. It is based on sealed deep groove ball bearings in the 62 and 63 series but have a convex outer ring and in most cases an extended inner ring with a specific locking device, enabling quick and easy mounting onto the shaft.
Cylindrical type bore
