Lovato Auxiliary Contact, 4 Contact, 3 NO/1 NC, BF00, DIN Rail, 10 A, BF0031D110
- RS Stock No.:
- 273-9261
- Mfr. Part No.:
- BF0031D110
- Brand:
- Lovato
Subtotal (1 unit)*
£120.41
(exc. VAT)
£144.49
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £120.41 |
*price indicative
- RS Stock No.:
- 273-9261
- Mfr. Part No.:
- BF0031D110
- Brand:
- Lovato
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lovato | |
| Product Type | Auxiliary Contact | |
| Number of Contacts | 4 | |
| Normal State Configuration | 3 NO/1 NC | |
| Series | BF00 | |
| Contact Current | 10A | |
| Mount Type | DIN Rail | |
| Terminal Type | Screw | |
| Pole and Throw Configuration | 4 | |
| Operational Current Ie | 0A | |
| Mechanical Durability | 20000000Cycles | |
| Mounting Location | Screw, DIN Rail | |
| Rated Insulation Voltage Ui | 690V | |
| Minimum Operating Temperature | -50°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | IEC/EN 60947-5-1, CSA C22.2 n° 60947-5-1, UL 60947-1, IEC/EN 60947-1, UL 60947-5-1, CSA C22.2 n° 60947-1 | |
| Select all | ||
|---|---|---|
Brand Lovato | ||
Product Type Auxiliary Contact | ||
Number of Contacts 4 | ||
Normal State Configuration 3 NO/1 NC | ||
Series BF00 | ||
Contact Current 10A | ||
Mount Type DIN Rail | ||
Terminal Type Screw | ||
Pole and Throw Configuration 4 | ||
Operational Current Ie 0A | ||
Mechanical Durability 20000000Cycles | ||
Mounting Location Screw, DIN Rail | ||
Rated Insulation Voltage Ui 690V | ||
Minimum Operating Temperature -50°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals IEC/EN 60947-5-1, CSA C22.2 n° 60947-5-1, UL 60947-1, IEC/EN 60947-1, UL 60947-5-1, CSA C22.2 n° 60947-1 | ||
- COO (Country of Origin):
- IT
The Lovato control relay with dc coil and four number of poles has maximum two number of wires simultaneously connectable. The maximum tightening torque for terminals is 1.8 Nm.
Pollution degree 3
EMC compatible
