Schneider Electric Auxiliary Contact Block, 2NO, DIN Rail Mount, TeSys D LA1D
- RS Stock No.:
- 211-2551
- Mfr. Part No.:
- LA1DX20
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£72.90
(exc. VAT)
£87.48
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £72.90 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 211-2551
- Mfr. Part No.:
- LA1DX20
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Normal State Configuration | 2NO | |
| Mounting Style | DIN Rail Mount | |
| Range | TeSys D | |
| Series | LA1D | |
| Contact Voltage Rating | 125 V ac | |
| Better World Product | Yes | |
| Better World Verification | Green Premium | |
Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Normal State Configuration 2NO | ||
Mounting Style DIN Rail Mount | ||
Range TeSys D | ||
Series LA1D | ||
Contact Voltage Rating 125 V ac | ||
Better World Product Yes | ||
Better World Verification Green Premium | ||
- COO (Country of Origin):
- FR
Schneider Electric LA1DX20
TeSys Deca instantaneous auxiliary contact block with dust and damp protected contacts, for LC1D contactors and CAD control relays in harsh industral environments. It provides 2NO protected contacts rated up to 0.1A 125V AC / 30V DC, connection by screw clamp terminals. Very low minimum switching capacity (5V / 1mA) thanks to gold alloy contact material. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
The Schneider Electric LA1 series TeSys D - auxiliary contact block, front mounting with screw clamp terminals.
Green Premium product
Instantaneous contact operation
IP degree of protection - IP20
Instantaneous contact operation
IP degree of protection - IP20
