Eaton Auxiliary Contact, 4 Contact, 2NC + 2NO, Front Mount
- RS Stock No.:
- 178-8011
- Mfr. Part No.:
- 139580 DILA-XHIR22
- Brand:
- Eaton
Subtotal (1 unit)*
£41.59
(exc. VAT)
£49.91
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 7 unit(s) shipping from 24 November 2025
- Plus 2 unit(s) shipping from 24 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £41.59 |
*price indicative
- RS Stock No.:
- 178-8011
- Mfr. Part No.:
- 139580 DILA-XHIR22
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Contacts | 4 | |
| Normal State Configuration | 2NC + 2NO | |
| Mounting Style | Front Mount | |
| Contact Current Rating | 10 A dc, 4 A ac | |
| Terminal Type | Screw | |
| Pole and Throw Configuration | 4P | |
| Contact Voltage Rating | 220 V dc, 500 V ac | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +60°C | |
| Operating Temperature Range | -25 → +60 °C | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Contacts 4 | ||
Normal State Configuration 2NC + 2NO | ||
Mounting Style Front Mount | ||
Contact Current Rating 10 A dc, 4 A ac | ||
Terminal Type Screw | ||
Pole and Throw Configuration 4P | ||
Contact Voltage Rating 220 V dc, 500 V ac | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +60°C | ||
Operating Temperature Range -25 → +60 °C | ||
RoHS Status: Exempt
Eaton Auxiliary Contact, Screw Terminals, 45mm Depth - DILA Series - 139580 DILA-XHIR22
Step up your contactor's functions with this auxiliary contact from Eaton. As it comes with four contacts in a 2NO and 2NC configuration, you can use it to take on extra control tasks such as on-and-off signalling and contactor monitoring. The contacts are set to be interlocked and opposing to ensure switching is carried out safely, helping to protect your equipment. Fitted with a microswitch, this device works reliably with electronics, enabling low-current switching in dusty environments and use in failsafe functions. This means it's handy for automation processes in industries including chemical processing and materials manufacturing.
Features & Benefits
• Clicks onto the front of your contactor for fuss-free mounting
• Screw terminals give you a straightforward and dependable connection
• Long lifespan of 10 million mechanical operations keeps it durable
• Capable of 9000 operations per hour for handling fast processes
• Wide operating temperature range between -25°C and +60°C for safe installation in extreme conditions
• Screw terminals give you a straightforward and dependable connection
• Long lifespan of 10 million mechanical operations keeps it durable
• Capable of 9000 operations per hour for handling fast processes
• Wide operating temperature range between -25°C and +60°C for safe installation in extreme conditions
What contactors does this unit work with?
This auxiliary contact pairs reliably with Eaton's DILA and DILM7 to DILM38 contactors (such as 493-0573 and 743-4885).
Note
Eaton formerly known as Moeller
