Paulstra Hutchinson Diamond, Square M10 Anti Vibration Mount, Female Buffer Foot
- RS Stock No.:
- 386-7604
- Mfr. Part No.:
- 810780
- Brand:
- Paulstra Hutchinson
Bulk discount available
Subtotal (1 unit)*
£46.82
(exc. VAT)
£56.18
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 13 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £46.82 |
| 5 - 9 | £45.42 |
| 10 + | £43.92 |
*price indicative
- RS Stock No.:
- 386-7604
- Mfr. Part No.:
- 810780
- Brand:
- Paulstra Hutchinson
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Paulstra Hutchinson | |
| Anti Vibration Mount Type | Female Buffer Foot | |
| Thread Size | M10 | |
| Diameter | 60mm | |
| Overall Height | 40mm | |
| Static Load Capacity | 60daN | |
| Material | Rubber | |
| Foot Shape | Diamond, Square | |
| Compression Deflection | 10mm | |
| Series | EVIDGOM | |
| Select all | ||
|---|---|---|
Brand Paulstra Hutchinson | ||
Anti Vibration Mount Type Female Buffer Foot | ||
Thread Size M10 | ||
Diameter 60mm | ||
Overall Height 40mm | ||
Static Load Capacity 60daN | ||
Material Rubber | ||
Foot Shape Diamond, Square | ||
Compression Deflection 10mm | ||
Series EVIDGOM | ||
- COO (Country of Origin):
- FR
Evidgom – Low Frequency Mount
Highly elasticity mounting for low frequency applications
Suitable for low speed rotating machines, fans, conveyors, hoppers, vibrating tables, crushers etc.
Provides more than 90% isolation at 1500rpm (25Hz)
Low natural frequency (2.5 to 7Hz)
High axial and radial elasticity
Available with bonded-in fixing bushes
Provides more than 90% isolation at 1500rpm (25Hz)
Low natural frequency (2.5 to 7Hz)
High axial and radial elasticity
Available with bonded-in fixing bushes
