RS PRO Cylindrical M8 Anti Vibration Mount, Female Buffer Foot with 48kg Compression Load

View all Anti Vibration Mounts

Subtotal (1 pack of 2 units)*

£15.01

(exc. VAT)

£18.012

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 310 unit(s) ready to ship
  • Plus 50 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 +£7.505£15.01

*price indicative

RS Stock No.:
185-4484
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Anti Vibration Mount Type

Female Buffer Foot

Thread Size

M8

Diameter

30mm

Overall Height

20mm

Material

Stainless Steel

Shore Hardness

55 Shore A

Metalwork

Stainless Steel

Compression Load

48kg

Foot Shape

Cylindrical

COO (Country of Origin):
IN

RS PRO Cylindrical Bobbin Mount


The RS PRO female/foot cylindrical bobbin mount has a thread size of M8 and dimensions of 30mm x 20mm (diameter x height). This stainless steel (316 grade) bobbin mount has a shore hardness of 55ShoreA and can be used in either compression and/or shear.

Features and Benefits


• Simple and cost-effective vibration isolators
• Compression load: 48kg

Applications


• Static generator engines
• Compressors
• Motors

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
