Maxim Integrated, Octal 12 bit- ADC 100ksps, 28-Pin SOIC
- RS Stock No.:
- 191-4262
- Mfr. Part No.:
- MAX197BEWI+
- Brand:
- Maxim Integrated
50 In stock - FREE next working day delivery available
Added
Price Each (In a Tube of 25)
£24.327
(exc. VAT)
£29.192
(inc. VAT)
| Units | Per unit | Per Tube* |
| 25 + | £24.327 | £608.175 |
| *price indicative | ||
- RS Stock No.:
- 191-4262
- Mfr. Part No.:
- MAX197BEWI+
- Brand:
- Maxim Integrated
Technical Reference
Legislation and Compliance
Product Details
12-Bit Resolution, 1/2LSB Linearity
Single +5V Operation
Software-Selectable Input Ranges: ±10V, ±5V, 0V to 10V, 0V to 5V
Fault-Protected Input Multiplexer (±16.5V)
8 Analog Input Channels
6μs Conversion Time, 100ksps Sampling Rate
Internal or External Acquisition Control
Internal 4.096V or External Reference
Two Power-Down Modes
Internal or External Clock
Applications/Uses
Automated Test Equipment (ATE)
Data Acquisition
Industrial Controls Systems
Medical Instruments
Robotics
Telecommunications
Single +5V Operation
Software-Selectable Input Ranges: ±10V, ±5V, 0V to 10V, 0V to 5V
Fault-Protected Input Multiplexer (±16.5V)
8 Analog Input Channels
6μs Conversion Time, 100ksps Sampling Rate
Internal or External Acquisition Control
Internal 4.096V or External Reference
Two Power-Down Modes
Internal or External Clock
Applications/Uses
Automated Test Equipment (ATE)
Data Acquisition
Industrial Controls Systems
Medical Instruments
Robotics
Telecommunications
Specifications
Attribute | Value |
|---|---|
| Architecture | SAR |
| Number of ADCs | 8 |
| Resolution | 12 bit |
| Sampling Rate | 100ksps |
| Input Signal Type | Single Ended |
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Pin Count | 28 |
| Integral Nonlinearity Error | ±1LSB |
| Digital Interface Type | Parallel |
| Power Supply Type | Single |
| Typical Single Supply Voltage | 4.75 to 5.25 V |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 18.1 x 7.6 x 2.35mm |
| Maximum Operating Temperature | 85 °C |
