Analog Devices, 12 bit- ADC 100ksps, 28-Pin SOIC
- RS Stock No.:
- 183-1822
- Mfr. Part No.:
- AD1674JRZ
- Brand:
- Analog Devices
Discontinued
- RS Stock No.:
- 183-1822
- Mfr. Part No.:
- AD1674JRZ
- Brand:
- Analog Devices
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Analog Devices | |
| Architecture | SAR | |
| Number of ADCs | 1 | |
| Resolution | 12 bit | |
| Sampling Rate | 100ksps | |
| Input Signal Type | Single Ended | |
| Input Type | Single Ended | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Pin Count | 28 | |
| Integral Nonlinearity Error | ±1LSB | |
| Digital Interface Type | Parallel | |
| Power Supply Type | Dual, Single | |
| Typical Single Supply Voltage | 4.5 to 5.5 V | |
| Minimum Operating Temperature | 0 °C | |
| Dimensions | 18.1 x 7.6 x 2.35mm | |
| Maximum Operating Temperature | 70 °C | |
| Select all | ||
|---|---|---|
Brand Analog Devices | ||
Architecture SAR | ||
Number of ADCs 1 | ||
Resolution 12 bit | ||
Sampling Rate 100ksps | ||
Input Signal Type Single Ended | ||
Input Type Single Ended | ||
Mounting Type Surface Mount | ||
Package Type SOIC | ||
Pin Count 28 | ||
Integral Nonlinearity Error ±1LSB | ||
Digital Interface Type Parallel | ||
Power Supply Type Dual, Single | ||
Typical Single Supply Voltage 4.5 to 5.5 V | ||
Minimum Operating Temperature 0 °C | ||
Dimensions 18.1 x 7.6 x 2.35mm | ||
Maximum Operating Temperature 70 °C | ||
Complete Monolithic 12-Bit 10 μs Sampling ADC
On-Board Sample-and-Hold Amplifier
Industry Standard Pinout
8- and 16-Bit Microprocessor Interface
AC and DC Specified and Tested
Unipolar and Bipolar Inputs
±5 V, ±10 V, 0 V–10 V, 0 V–20 V Input Ranges
On-Board Sample-and-Hold Amplifier
Industry Standard Pinout
8- and 16-Bit Microprocessor Interface
AC and DC Specified and Tested
Unipolar and Bipolar Inputs
±5 V, ±10 V, 0 V–10 V, 0 V–20 V Input Ranges
