HA9P2556-9Z Renesas Electronics, 4-quadrant Voltage Multiplier, 50 MHz, 16-Pin SOIC W
- RS Stock No.:
- 921-5696
- Mfr. Part No.:
- HA9P2556-9Z
- Brand:
- Renesas Electronics
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 921-5696
- Mfr. Part No.:
- HA9P2556-9Z
- Brand:
- Renesas Electronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Renesas Electronics | |
| Number of Quadrants | 4 | |
| Output Type | Single Ended | |
| Number of Elements per Chip | 1 | |
| Maximum Supply Current | 22 mA | |
| Maximum Operating Frequency | 50 MHz | |
| Maximum Dual Supply Voltage | ±15V | |
| Minimum Dual Supply Voltage | ±5V | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC W | |
| Pin Count | 16 | |
| Maximum Operating Temperature | +85 °C | |
| Height | 2.35mm | |
| Length | 10.5mm | |
| Dimensions | 10.5 x 7.6 x 2.35mm | |
| Minimum Operating Temperature | -40 °C | |
| Width | 7.6mm | |
Select all | ||
|---|---|---|
Brand Renesas Electronics | ||
Number of Quadrants 4 | ||
Output Type Single Ended | ||
Number of Elements per Chip 1 | ||
Maximum Supply Current 22 mA | ||
Maximum Operating Frequency 50 MHz | ||
Maximum Dual Supply Voltage ±15V | ||
Minimum Dual Supply Voltage ±5V | ||
Mounting Type Surface Mount | ||
Package Type SOIC W | ||
Pin Count 16 | ||
Maximum Operating Temperature +85 °C | ||
Height 2.35mm | ||
Length 10.5mm | ||
Dimensions 10.5 x 7.6 x 2.35mm | ||
Minimum Operating Temperature -40 °C | ||
Width 7.6mm | ||
