Powering Innovation with Infineon Gate Drivers

Infineon’s gate driver solutions are engineered to meet the demands of modern power electronics—delivering efficiency, reliability, and compact design for industrial, automotive, and energy applications. Whether you're designing motor drives, renewable energy systems, or high-voltage converters, Infineon provides the tools to drive innovation forward.

Efficient Power Integration with the 2EP Family – Transformer Driver Ics

2EP Family

The 2EP1xxR family of transformer driver ICs is designed to simplify the creation of isolated power supplies for gate drivers. These full-bridge drivers integrate power management and asymmetric voltage generation, making them ideal for powering a wide range of switches including IGBTs, MOSFETs, GaN HEMTs, and SiC MOSFETs. Whether you're working with TRENCHSTOP™, OptiMOS™, CoolMOS™, CoolGaN™, or CoolSiC™ technologies, the 2EP family ensures seamless compatibility and performance.

These drivers are particularly well-suited for applications where a regulated voltage rail is available and an isolated supply is needed—such as industrial motor drives (including servo and premium models), solar inverters, UPS systems, welding equipment, commercial HVAC systems, and high-voltage DC-DC or DC-AC converters. Their compact design and integrated protection features reduce system complexity and save board space, while flexible duty cycle control and wide frequency support enable transformer size optimization and cost-effective implementation.

Key Features:

  • Wide input supply range: 4.5 V to 20 V
  • Supports up to 5 W output power
  • Frequency range: 50 kHz to 695 kHz
  • Adjustable duty cycle: 10% to 50%
  • Overcurrent, short circuit, and overtemperature protection
Explore the 2EP Family

Discover 2ED314x_Lynx EiceDRIVER™ High-Density Dual-Channel Gate Drivers for Demanding Applications

2ED Infineon

The 2ED314x_Lynx EiceDRIVER™ Compact family offers dual-channel isolated gate drivers optimized for high-performance power devices including IGBTs, silicon MOSFETs, and SiC MOSFETs. These drivers are built for environments where power density, reliability, and safety are critical—such as DIN rail power supplies, energy storage systems, EV charging stations, and general-purpose motor drives.

With galvanic isolation via coreless transformer technology and high common-mode transient immunity, these drivers ensure robust operation even in electrically noisy environments. Their compact footprint and dual-channel configuration help reduce board space and simplify layout, while features like active shutdown, short circuit clamping, and dead time control enhance system safety and performance. The 2ED314x_Lynx family is also ready for SiC applications, offering fast propagation delays and high output current for efficient switching.

Key Features:

  • Supports 600 V to 2300 V IGBTs and MOSFETs
  • Up to 6.5 A peak output current
  • 39 ns propagation delay
  • High CMTI > 200 kV/µs
  • UL 1577 isolation rating up to 6.84 kV
Discover the range

Resources

2EP1 Datasheet (PDF 871.2KB)2ED314 Datasheet (PDF 4.4MB)
