- RS Stock No.:
- 214-5256
- Mfr. Part No.:
- 022816
- Brand:
- W Robinson And Sons
1 In stock - FREE next working day delivery available
Added
Price Each
£551.72
(exc. VAT)
£662.06
(inc. VAT)
Units | Per unit |
1 + | £551.72 |
- RS Stock No.:
- 214-5256
- Mfr. Part No.:
- 022816
- Brand:
- W Robinson And Sons
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
Bore Hole Pump
Compact, submersible brass pump for use with clean water
Ideal for drinking water supplies, domestic water supplies etc
Pumps design eliminates risk of blocking and burning of motor, which is common in cast iron pumps because of oxidation in the small gap between impeller and casing
Reliable motor with water bath rotor (canned type) eliminates risk of contaminating drinking water
Class F motor, with class H windings, has high starting torque with the only run capacitor (PSC) mode in corrosion proof material
316mm high
Incorporates automatic overload protection
Ideal for drinking water supplies, domestic water supplies etc
Pumps design eliminates risk of blocking and burning of motor, which is common in cast iron pumps because of oxidation in the small gap between impeller and casing
Reliable motor with water bath rotor (canned type) eliminates risk of contaminating drinking water
Class F motor, with class H windings, has high starting torque with the only run capacitor (PSC) mode in corrosion proof material
316mm high
Incorporates automatic overload protection
Note
Maximum liquid temperature during continuous operation: 35°C
Specifications
Attribute | Value |
---|---|
Supply Voltage | 230 V |
Maximum Head | 55m |
Body Material | Brass |
Input Power | 1150W |
Maximum Fluid Temperature | +50°C |
Output Connection Size | 4in |
Pump Type | Submersible |
- RS Stock No.:
- 214-5256
- Mfr. Part No.:
- 022816
- Brand:
- W Robinson And Sons
