    Product Details

    LMR Nano SIMPLE SWITCHER® Step-Down Regulator Series


    Input Voltage up to 42V (LMRx42xx), 20V (LMRx20xx), and 5.5V (LMRx05xx)
    Output Current up to 2A (LMRxxx20), 1.5A (LMRxxx15), 1A (LMRxxx10), etc.
    Adjustable output voltage from 0.6V
    1MHz or greater switching frequency of 1.6MHz (LMR.....X) and 3MHz (LMR.....Y)
    Low Shutdown Quiescent Current
    Internal Soft-start
    Thermal Shutdown



    SIMPLE SWITCHER® Regulators, Texas Instruments


    Use for wide voltage inputs designs up to 75V, and a balance between ease of use and flexibility.


    Specifications

    AttributeValue
    Controller TypeStep Down
    Number of Outputs1
    Maximum Switching Frequency1.95 MHz
    Width3mm
    Mounting TypeSurface Mount
    Package TypeWSON
    Pin Count6
    Dimensions3 x 3 x 0.8mm
    Length3mm
    Height0.8mm
    Maximum Input Voltage5.5 V
    Maximum Operating Temperature+125 °C
    Maximum Output Current2A
    Maximum Output Voltage4.5 V
    Minimum Operating Temperature-40 °C
    Minimum Output Voltage0.6 V
    Minimum Input Voltage3 V
